Rear axle Diagram Honda CIVIC
- Year
- 1995
- Model code
- CIVIC
- Sales region
- General
- Engine
- D16Z
- transmission
- 5MT
- Number of doors
- 4
- grade
- RTSI
- area code
- KG
- left-hand drive
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
50300-SR7-A00
Beam
|
50300-SR7-A00 |
— | ||
|
2
|
2
50710-SR7-J00 Mounting comp. aRR. DIFFERENTIAL |
50710-SR7-J00 |
US $160 |
||
|
3
|
3
50711-SH9-020 Rubber aRR. DIFFERENTIAL INSULATOR |
50711-SH9-020 |
US $23.99 |
||
|
4
|
4
50712-SH9-010 Plate |
50712-SH9-010 |
US $8.47 |
||
|
5
|
5
50713-SH9-010
Stopper a
|
50713-SH9-010 |
— | ||
|
6
|
6
50716-SR7-J00
Damper
|
50716-SR7-J00 |
— | ||
|
7
|
7
50721-SH9-010 Rubber bRR. DIFFERENTIAL INSULATOR |
50721-SH9-010 |
US $36.74 |
||
|
8
|
8
50725-SH7-900 Bracket bR. RR. DIFFERENTIAL MOUNTING |
50725-SH7-900 |
US $17.41 |
||
|
9
|
9
50726-SH7-901 Bracket bL. RR. DIFFERENTIAL MOUNTING |
50726-SH7-901 |
US $14.98 |
||
|
10
|
10
90161-SH5-000
Bolt
|
90161-SH5-000 |
— | ||
|
11
|
11
90163-SR7-010 BoltFLANGE, 10X119 |
90163-SR7-010 |
US $5.21 |
||
|
13
|
13
90504-SH3-000
Washer
|
90504-SH3-000 |
— | ||
|
14
|
14
91613-SR3-003 GrommetSUB FRAME, 15MM |
91613-SR3-003 |
US $1.26 |
||
|
15
|
15
94101-12800 WasherPLAIN, 12MM |
94101-12800 |
from US $0.41 |
||
|
16
|
16
95701-100-200-8 BoltFLANGE, 10X20 |
95701-100-200-8 |
from US $0.74 |
||
|
18
|
18
95801-120-650-8 BoltFLANGE, 12X65 |
95801-120-650-8 |
US $1.48 |
||
|
19
|
19
95801-120-800-8 BoltFLANGE, 12X80 |
95801-120-800-8 |
US $1.48 |
||
|
20
|
20
95801-120-950-8 BoltFLANGE, 12X95 |
95801-120-950-8 |
US $1.63 |
