Fuel strainer & fuel hose (2007-08-01 ~ 2009-08-01; F/STD; QR25DE) Diagram Nissan ROGUE
- Year
- 2007 - 2009
- Sales region
- U.S.A.
- Engine
- QR25DE
- drive
- 4WD
- transmission
- CVT/MCVT
- grade
- S
- body
- HB
- area
- FED
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
081A68161A
|
081A68161A
081A68161A
BOLTFLANGE
|
081A68161A |
— | ||
|
081A68161A
|
081A68161A
081A68161A
BOLTFLANGE
|
081A68161A |
— | ||
|
16412F
|
16412F
16618-5M100 Seal-O Ring2007-08-01 ~ 2009-08-01; FED.QR25DE; , |
16618-5M100 |
from US $4.18 |
||
|
16412F
|
16412F
16618-AX200 Seal-O Ring2007-08-01 ~ 2009-08-01; FED.QR25DE; , |
16618-AX200 |
from US $4.18 |
||
|
16412FA
|
16412FA
16618-AX200 Seal-O Ring2007-08-01 ~ 2009-08-01; FED.QR25DE; , |
16618-AX200 |
from US $4.18 |
||
|
16441X
|
16441X
164416N210 Release-Quick Connector2007-08-01 ~ 2009-08-01; QR25DE; , |
164416N210 |
from US $10.37 |
||
|
16454
|
16454
175308H300 Connector2007-08-01 ~ 2009-08-01; QR25DE; , |
175308H300 |
from US $15.84 |
||
|
16603
|
16603
16600-JA000 Injector Assy-Fuel2007-08-01 ~ 2009-08-01; FED.QR25DE; , |
16600-JA000 |
US $190.08 |
||
|
16603
|
16603
175715L30A Clamp-Injector2007-08-01 ~ 2009-08-01; QR25DE; , |
175715L30A |
from US $0.97 |
||
|
16603E
|
16603E
175715L30A Clamp-Injector2007-08-01 ~ 2009-08-01; QR25DE; , |
175715L30A |
from US $0.97 |
||
|
16883
|
16883
24220CR900 Clip2007-08-01 ~ 2009-08-01; QR25DE; , |
24220CR900 |
from US $2.63 |
||
|
173
|
Fuel piping
173
|
||||
|
173
|
Fuel piping
173
|
||||
|
173
|
Fuel piping
173
|
||||
|
17520
|
17520
17520-ET80B Tube Assy-Fuel2007-08-01 ~ 2009-08-01; QR25DE; , |
17520-ET80B |
US $68.11 |
||
|
223
|
Vacuum piping
223
|
||||
|
24271Y
|
24271Y
16265-JG30A Protector-Hose2007-08-01 ~ 2009-08-01; QR25DE; , |
16265-JG30A |
US $5.33 |
||
