Delivery pipe (QR25DE) Diagram Suzuki EQUATOR
- Year
- -
- Sales region
- U.S.A.
- drive
- 2WD
- transmission
- MT
- grade
- STD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
15711-82Z10-000
O ring
|
15711-82Z10-000 |
— | ||
|
2
|
2
15711-82Z30-000
O ring
|
15711-82Z30-000 |
— | ||
|
2
|
2
15711-82Z50-000
O ring
|
15711-82Z50-000 |
— | ||
|
3
|
3
15710-82Z10-000
Injector assy, fuel
|
15710-82Z10-000 |
— | ||
|
4
|
4
15715-50Z01-000
カバー,インジェクタ
|
15715-50Z01-000 |
— | ||
|
5
|
5
15880-82Z00-000
Hose, fuel
|
15880-82Z00-000 |
— | ||
|
6
|
6
15750-50Z00-000
コネクタ
|
15750-50Z00-000 |
— | ||
|
7
|
7
15879-82Z00-000
Clip
09 MODEL |
15879-82Z00-000 |
— | ||
|
7
|
7
15879-82Z10-000
Clip
10 MODEL |
15879-82Z10-000 |
— | ||
|
8
|
8
15893-82Z60-000
Clamp
|
15893-82Z60-000 |
— | ||
|
9
|
9
15730-82Z00-000
Pipe, delivery
|
15730-82Z00-000 |
— | ||
|
10
|
10
27618-50Z00-000
ボルト,8X35
|
27618-50Z00-000 |
— |
