Rear suspension frame (4WD) Diagram Suzuki KIZASHI
- Year
- -
- Sales region
- Canada
- drive
- 4WD
- transmission
- MT
- grade
- SPORT
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
46274-57L00-000 BOLT,RR SPNSN FRAME FRONT |
46274-57L00-000 |
from US $15.57 |
||
|
2
|
2
46275-57L00-000 NUT,RR SPNSN FRAME FR |
46275-57L00-000 |
from US $9.32 |
||
|
3
|
3
46276-57L00-000 BOLT,RR SPNSN FRAME REAR |
46276-57L00-000 |
from US $9.32 |
||
|
4
|
4
46700-57810-000 FRAME SET,RR SPNSN |
46700-57810-000 |
US $1,441.36 |
||
|
5
|
5
46801-57L00-000 BAR,RR FRAME FR,R |
46801-57L00-000 |
from US $20.25 |
||
|
6
|
6
46802-57L00-000 BAR,RR FRAME FR,L |
46802-57L00-000 |
from US $20.25 |
||
|
7
|
7
46912-57L00-000 STOPPER,REAR SPNSN FRAME |
46912-57L00-000 |
from US $7.58 |
||
|
8
|
8
46921-57L01-000 WASHER,RR SPNSN FRAME MOUNT |
46921-57L01-000 |
US $6.81 |
||
|
9
|
9
46924-57L00-000 BOLT,RR FRAME BAR FR |
46924-57L00-000 |
US $6.07 |
