Rear Spring & Shock Absorber ([04.1990 - ] (9004- )ACT) Diagram Toyota CELICA
- Year
- 1990 - 1991
- Sales region
- Japan
- Frame
- ST183
- grade
- ACT
- body
- LB
- ENGINE
- 3SGE
- TRANSMISSION
- MTM
- From
- 04.1990
- To
- 08.1991
- Body Shape
- NOB
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31478J
|
31478J
31478-20020 Cap, Rear Shock Absorber Bleeder Plug, Rh[04.1990 - 08.1991] ST183..ACT |
31478-20020 |
US $2.48 |
||
|
31478K
|
31478K
31478-20020 Cap, Rear Shock Absorber Bleeder Plug, Rh[04.1990 - 08.1991] ST183..ACT |
31478-20020 |
US $2.48 |
||
|
42304
|
42304
42304-29045
Carrier Sub-Assy, Rear Axle, Rh
[04.1990 - 09.1993] ST183..ACT,CV |
42304-29045 |
— | ||
|
42304A
|
42304A
90105-15003 Bolt (For Rear Axle Carrier)[04.1990 - 08.1991] ST183..ACT |
90105-15003 |
US $8.30 |
||
|
42304B
|
42304B
90179-15001 Nut (For Rear Axle Carrier)[09.1989 - 09.1993] ST18# |
90179-15001 |
US $5.60 |
||
|
42305
|
42305
42305-29045
Carrier Sub-Assy, Rear Axle, Lh
[04.1990 - 09.1993] ST183..ACT,CV |
42305-29045 |
— | ||
|
47547V
|
47547V
47547-20010 Plug, Bleeder(For Release Cylinder)[04.1990 - 08.1991] ST183..ACT |
47547-20010 |
from US $3.20 |
||
|
47547W
|
47547W
47547-20010 Plug, Bleeder(For Release Cylinder)[04.1990 - 08.1991] ST183..ACT |
47547-20010 |
from US $3.20 |
||
|
48071
|
48071
48071-20100 Support Sub-Assy, Rear Suspension, Rh[04.1990 - 08.1991] ST183..ACT |
48071-20100 |
US $97.55 |
||
|
48072
|
48072
48072-20050 Support Sub-Assy, Rear Suspension, Lh[04.1990 - 08.1991] ST183..ACT |
48072-20050 |
US $97.55 |
||
|
48231A
|
48231A
48231-20830 Spring, Coil, Rear Rh[04.1990 - 08.1991] ST183..ACT |
48231-20830 |
US $75.71 |
||
|
48231B
|
48231B
48231-20830 Spring, Coil, Rear Rh[04.1990 - 08.1991] ST183..ACT |
48231-20830 |
US $75.71 |
||
|
48257C
|
48257C
48257-20020 Insulator, Rear Coil Spring, Upper Rh[04.1990 - 08.1991] ST183..ACT |
48257-20020 |
US $8.30 |
||
|
48258B
|
48258B
48258-20020 Insulator, Rear Coil Spring, Lower Rh[04.1990 - 08.1991] ST183..ACT |
48258-20020 |
US $16.02 |
||
|
48258C
|
48258C
48258-20020 Insulator, Rear Coil Spring, Lower Rh[04.1990 - 08.1991] ST183..ACT |
48258-20020 |
US $16.02 |
||
|
48259A
|
48259A
48257-20020 Insulator, Rear Coil Spring, Upper Rh[04.1990 - 08.1991] ST183..ACT |
48257-20020 |
US $8.30 |
||
|
48341A
|
48341A
48341-20170
Bumper, Rear Spring
[04.1990 - 08.1991] ST183..ACT |
48341-20170 |
— | ||
|
48341B
|
48341B
48341-20170
Bumper, Rear Spring
[04.1990 - 08.1991] ST183..ACT |
48341-20170 |
— | ||
|
48481A
|
48481A
48481-20010 Seat, Rear Coil Spring, Upper Rh[04.1990 - 08.1991] ST183..ACT |
48481-20010 |
US $24.17 |
||
|
48482
|
48482
48482-20070 Seat, Rear Spring, Upper Lh[04.1990 - 08.1991] ST183..ACT |
48482-20070 |
US $24.17 |
||
|
48553A
|
48553A
48553-20030 Cap, Shock Absorber[04.1990 - 08.1991] ST183..ACT |
48553-20030 |
US $16.02 |
||
|
48559C
|
48559C
45222-20030 Cover, Rear Shock Absober Dust, Rh No.1[04.1990 - 08.1991] ST183..ACT |
45222-20030 |
US $7.13 |
||
|
48559D
|
48559D
45222-20030 Cover, Rear Shock Absober Dust, Rh No.1[04.1990 - 08.1991] ST183..ACT |
45222-20030 |
US $7.13 |
||
|
48559J
|
48559J
90460-70001 Clamp, Hose[04.1990 - 08.1991] ST183..ACT |
90460-70001 |
US $6.99 |
||
| replacement | |||||
|
48559J
|
48559J
90467-56001 Clamp Or Clip(For Air Hose, No.1)[04.1990 - 08.1991] ST183..ACT |
90467-56001 |
from US $8.64 |
||
|
48559K
|
48559K
90460-70001 Clamp, Hose[04.1990 - 08.1991] ST183..ACT |
90460-70001 |
US $6.99 |
||
| replacement | |||||
|
48559K
|
48559K
90467-56001 Clamp Or Clip(For Air Hose, No.1)[04.1990 - 08.1991] ST183..ACT |
90467-56001 |
from US $8.64 |
||
|
48703D
|
48703D
90209-13005 Washer(For Rear Suspension Arm)[09.1989 - 09.1993] ST183,185 |
90209-13005 |
US $8.80 |
||
|
48703E
|
48703E
90105-12192 Bolt(For Rear Suspension Arm)[09.1989 - 09.1993] ST183 ＊１２−１．２５ＰＸ７２−３０ |
90105-12192 |
US $5.39 |
||
|
48710A
|
48710A
48710-20141 Arm Assy, Rear Suspension, No.1 Rh[04.1990 - 08.1991] ST183..ACT |
48710-20141 |
US $131.04 |
||
|
48720A
|
48720A
48720-20081 Arm Assy, Rear Suspension, No.1 Lh[04.1990 - 08.1991] ST183..ACT |
48720-20081 |
US $131.04 |
||
|
48750G
|
48750G
90179-08122 Nut(For Rear Suspension Support)[09.1989 - 09.1993] ST18# |
90179-08122 |
US $7.04 |
||
|
48753B
|
48753B
48753-20020 Cover, Rear Suspension Supoport, No.1 Rh[04.1990 - 08.1991] ST183..ACT |
48753-20020 |
US $26.21 |
||
|
48753C
|
48753C
48753-20020 Cover, Rear Suspension Supoport, No.1 Rh[04.1990 - 08.1991] ST183..ACT |
48753-20020 |
US $26.21 |
||
|
48780A
|
48780A
48780-20070
Rod Assy, Strut, Rear
[09.1989 - 09.1993] ST183 |
48780-20070 |
— | ||
|
48780B
|
48780B
90119-12131 Bolt(For Strut Rod)[09.1989 - 09.1993] ST183 |
90119-12131 |
from US $3.63 |
||
| replacement | |||||
|
48780B
|
48780B
90080-11133 Bolt(For Strut Rod)[09.1989 - 09.1993] ST183 |
90080-11133 |
US $10.95 |
||
|
48780C
|
48780C
90171-12008
Nut(For Strut Rod)
[09.1989 - 09.1993] ST183 CARRIER SIDE |
90171-12008 |
— | ||
|
48780C
|
48780C
90179-12065
Nut(For Strut Rod)
[09.1989 - 09.1993] ST18# BODY SIDE |
90179-12065 |
— | ||
|
49167
|
49167
49167-20021 Hose, Suspension Control Pressure, No.7[04.1990 - 08.1991] ST183..ACT |
49167-20021 |
US $251.89 |
||
|
49167A
|
49167A
96711-19033 Ring, O (For Shift Lever)[04.1990 - 08.1991] ST183..ACT |
96711-19033 |
US $4.32 |
||
|
49168
|
49168
49168-20022 Hose, Suspension Control Pressure, No.8[04.1990 - 08.1991] ST183..ACT |
49168-20022 |
US $308.67 |
||
|
49168A
|
49168A
96711-19033 Ring, O (For Shift Lever)[04.1990 - 08.1991] ST183..ACT |
96711-19033 |
US $4.32 |
||
|
49187
|
49187
49187-20011 Hose, Suspension Control Drain, No.7[04.1990 - 08.1991] ST183..ACT |
49187-20011 |
US $46.30 |
||
|
49188
|
49188
49188-20010 Hose, Suspension Control Drain, No.8[04.1990 - 08.1991] ST183..ACT |
49188-20010 |
US $46.30 |
||
|
49197
|
49197
49197-20012 Bracket, Suspension Control Drain Hose, Rear Rh[04.1990 - 08.1991] ST183..ACT |
49197-20012 |
US $10.92 |
||
|
49198
|
49198
49198-20021 Bracket, Suspension Control Drain Hose, Rear Lh[04.1990 - 08.1991] ST183..ACT |
49198-20021 |
US $10.48 |
||
|
9017914012
|
9017914012
90179-14012 Nut(For Rear Suspension Arm) |
90179-14012 |
US $3.84 |
||
|
9165160820
|
9165160820
91651-60820
Bolt, Radiator Side Support Plate
|
91651-60820 |
— | ||
| replacement | |||||
|
9165160820
|
9165160820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $1.05 |
||
|
9165540820
|
9165540820
91655-40820
New Genuine Part
|
91655-40820 |
— | ||
| replacement | |||||
|
9165540820
|
9165540820
91653-40820 BOLT, W/WASHER |
91653-40820 |
US $1.76 |
||
|
9461210800
|
9461210800
94612-10800 Washer, Plate(For Repair Actuator Set) |
94612-10800 |
from US $0.96 |
||
|
9538103020
|
9538103020
95381-03020 Pin, Cotter(For Reverse Shaft Restrict Pin) |
95381-03020 |
from US $0.78 |
||
|
9699110080
|
9699110080
96991-10080 CLIP |
96991-10080 |
from US $1.27 |
||
