Rear Spring & Shock Absorber ([10.1994 - ] (9410- )) Diagram Toyota CELSIOR
- Year
- 1997 - 2000
- Sales region
- Japan
- Frame
- UCF20
- grade
- A
- ENGINE
- 1UZFE
- From
- 07.1997
- To
- 08.2000
- Gear Shift Type
- 5FC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42304
|
42304
42304-50060
Carrier Sub-Assy, Rear Axle, Rh
[08.1996 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
42304-50060 |
— | ||
|
42304
|
42304
42304-50080
Carrier Sub-Assy, Rear Axle, Rh
[07.1997 - 08.2000] UCF2# |
42304-50080 |
— | ||
|
42304A
|
42304A
90119-14025 Bolt (For Rear Axle Carrier)[10.1994 -] UCF2# |
90119-14025 |
US $6.72 |
||
|
42304B
|
42304B
90179-14037 Nut (For Rear Axle Carrier)[10.1994 -] UCF2# |
90179-14037 |
US $2.80 |
||
|
42305
|
42305
42305-50060
Carrier Sub-Assy, Rear Axle, Lh
[08.1996 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
42305-50060 |
— | ||
|
42305
|
42305
42305-50080 Carrier Sub-Assy, Rear Axle, Lh[07.1997 - 08.2000] UCF2# |
42305-50080 |
US $257.71 |
||
|
48190R
|
48190R
48190-22030 Cam Assy, Camber Adjust[10.1994 -] UCF2# |
48190-22030 |
from US $6.26 |
||
|
48198R
|
48198R
48198-22020 Cam, Rear Suspension Camber Adjust, No.2 Rh[10.1994 -] UCF2# |
48198-22020 |
from US $13.12 |
||
|
48231A
|
48231A
48231-50120
Spring, Coil, Rear Rh
[07.1997 - 08.2000] UCF20 |
48231-50120 |
— | ||
|
48231A
|
48231A
48231-50130
Spring, Coil, Rear Rh
[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48231-50130 |
— | ||
|
48231B
|
48231B
48231-50120
Spring, Coil, Rear Rh
[07.1997 - 08.2000] UCF20 |
48231-50120 |
— | ||
|
48231B
|
48231B
48231-50130
Spring, Coil, Rear Rh
[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48231-50130 |
— | ||
|
48257B
|
48257B
48257-50010 Insulator, Rear Coil Spring, Upper[10.1994 -] UCF20 |
48257-50010 |
from US $28.65 |
||
|
48341
|
48341
48341-50050 Bumper, Rear Spring[07.1997 -] UCF20 |
48341-50050 |
from US $20.27 |
||
|
48530
|
48530
48530-59115 Absorber Assy, Shock, Rear Rh[07.1997 - 08.2000] UCF20 |
48530-59115 |
US $115.02 |
||
| replacement | |||||
|
48530
|
48530
48530-59097 Absorber Assy, Shock, Rear[07.1997 - 08.2000] UCF20 |
48530-59097 |
US $131.04 |
||
|
48530
|
48530
48530-59125
Absorber Assy, Shock, Rear
[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48530-59125 |
— | ||
| replacement | |||||
|
48530
|
48530
48530-59126 Absorber Assy, Shock, Rear[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48530-59126 |
US $131.04 |
||
|
48540
|
48540
48530-59115 Absorber Assy, Shock, Rear Rh[07.1997 - 08.2000] UCF20 |
48530-59115 |
US $115.02 |
||
| replacement | |||||
|
48540
|
48540
48530-59097 Absorber Assy, Shock, Rear[07.1997 - 08.2000] UCF20 |
48530-59097 |
US $131.04 |
||
|
48540
|
48540
48530-59125
Absorber Assy, Shock, Rear
[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48530-59125 |
— | ||
| replacement | |||||
|
48540
|
48540
48530-59126 Absorber Assy, Shock, Rear[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48530-59126 |
US $131.04 |
||
|
48553D
|
48553D
48553-50080
Cap, Rear Shock Absorber
[10.1994 -] UCF20 |
48553-50080 |
— | ||
|
48554A
|
48554A
48553-50080
Cap, Rear Shock Absorber
[10.1994 -] UCF20 |
48553-50080 |
— | ||
|
48703C
|
48703C
90179-12027 Nut, Castle (For Front Lower Ball Joint Setting)[10.1994 -] UCF2# |
90179-12027 |
from US $1.46 |
||
|
48710A
|
48710A
48710-50050 Arm Assy, Rear Suspension, No.1[07.1997 -] UCF2# |
48710-50050 |
from US $109.52 |
||
|
48720A
|
48720A
48720-50030 Arm Assy, Rear Suspension, No.1 Lh[07.1997 -] UCF2# |
48720-50030 |
from US $109.52 |
||
|
48724
|
48724
48724-50011
Damper, Lwr Control Arm Dynamic
[08.1995 -] UCF2# |
48724-50011 |
— | ||
|
48730A
|
48730A
48730-50021 Arm Assy, Rear Suspension, No.2[05.1996 - 08.2000] UCF2# |
48730-50021 |
US $102.12 |
||
|
48730A
|
48730A
48730-50031 Arm Assy, Rear Suspension, No.2[08.1996 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48730-50031 |
US $97.84 |
||
|
48750A
|
48750A
90177-12002 Nut[03.2000 -] UCF20 |
90177-12002 |
US $1.44 |
||
|
48750A
|
48750A
94187-11200
Nut
[10.1994 - 03.2000] UCF20 |
94187-11200 |
— | ||
| replacement | |||||
|
48750A
|
48750A
90177-12002 Nut[10.1994 - 03.2000] UCF20 |
90177-12002 |
US $1.44 |
||
|
48750G
|
48750G
90179-10088 Nut[10.1994 -] UCF2# |
90179-10088 |
from US $1.03 |
||
|
48755
|
48755
48755-50090 Support, Rear Suspension[07.1997 -] UCF20 |
48755-50090 |
from US $27.43 |
||
|
48770A
|
48770A
48770-59015 Arm Assy, Upper Control, Rear Rh[10.1994 - 08.2000] UCF2# |
48770-59015 |
US $260.33 |
||
|
48770A
|
48770A
48770-59025 Arm Assy, Upper Control, Rear Rh[08.1996 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48770-59025 |
US $216.65 |
||
|
48780A
|
48780A
48780-50021 Rod Assy, Strut, Rear[07.1997 -] UCF2# |
48780-50021 |
US $106.58 |
||
|
48790
|
48790
48790-59015 Arm Assy, Upper Control, Rear Lh[10.1994 - 08.2000] UCF2# |
48790-59015 |
US $260.33 |
||
|
48790
|
48790
48790-59025 Arm Assy, Upper Control, Rear Lh[08.1996 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48790-59025 |
US $260.33 |
||
|
48812
|
48812
48812-40070 Bar, Stabilizer, Rear[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48812-40070 |
US $115.32 |
||
|
48812
|
48812
48812-50100
Bar, Stabilizer, Rear
[07.1997 - 08.2000] UCF2# |
48812-50100 |
— | ||
|
48815R
|
48815R
48815-40060 Bush, Stabilizer(For Rear)[07.1997 - 08.2000] UCF20 ER ﾊﾞ-ｼﾞﾖﾝ *(G) |
48815-40060 |
US $12.32 |
||
|
48815R
|
48815R
48815-50160 Bush, Stabilizer(For Rear)[07.1997 - 08.2000] UCF2# |
48815-50160 |
from US $12.23 |
||
|
48824R
|
48824R
48824-50030 Bracket, Stabilizer(For Rear)[08.1995 -] UCF2# |
48824-50030 |
US $25.33 |
||
|
48830
|
48830
48830-22041 Link Assy, Rear Stabilizer[09.1995 -] UCF2# |
48830-22041 |
from US $49.20 |
||
|
48830A
|
48830A
90179-12052 Nut (For Front Lower Ball Joint Setting)[10.1994 -] UCF2# |
90179-12052 |
from US $1.54 |
||
|
9010512277
|
9010512277
90105-12277 New Genuine Part |
90105-12277 |
US $4.19 |
||
|
9011908661
|
9011908661
90119-08661
Bolt (For Transmission Control Cable Bracket)
|
90119-08661 |
— | ||
| replacement | |||||
|
9011908661
|
9011908661
91611-B0816 Bolt |
91611-B0816 |
from US $1.03 |
||
|
9011912284
|
9011912284
90119-12284 New Genuine Part |
90119-12284 |
US $4.19 |
||
|
9011914035
|
9011914035
90119-14035 Bolt(For Rear Suspension Arm) |
90119-14035 |
from US $3.28 |
||
|
9011914040
|
9011914040
90119-14040 Bolt(For Rear Upper Control Arm) |
90119-14040 |
US $8.32 |
||
|
9017012038
|
9017012038
90170-12038 New Genuine Part |
90170-12038 |
US $1.05 |
||
|
9017014012
|
9017014012
90170-14012 Nut, Rack End Lock |
90170-14012 |
from US $1.09 |
||
|
9017908184
|
9017908184
90179-08184 NUT |
90179-08184 |
US $1.44 |
||
|
9017912137
|
9017912137
90179-12137 New Genuine Part |
90179-12137 |
US $1.40 |
||
|
9017912138
|
9017912138
90179-12138 NUT WWASHER |
90179-12138 |
from US $2.57 |
||
|
9017914015
|
9017914015
90179-14015 Nut, Castle (For Front Lower Ball Joint Setting) |
90179-14015 |
from US $1.93 |
||
|
9017914045
|
9017914045
90179-14045 Nut(For Front Shock Absorber Bracket Lower) |
90179-14045 |
from US $1.42 |
||
|
9020112071
|
9020112071
90201-12071 WASHER PLATE |
90201-12071 |
US $3.52 |
||
|
9020114020
|
9020114020
90201-14020 WASHER |
90201-14020 |
from US $1.01 |
||
|
9411041000
|
9411041000
94110-41000 Nut(For Steering Damper) |
94110-41000 |
US $2.56 |
||
|
9413061000
|
9413061000
94130-61000 Nut(For Clutch Pedal Stopper) |
94130-61000 |
from US $0.84 |
||
