Center Support & Planetary Sun Gear (Atm) ([08.1979 - ] (7908- )3FC) Diagram Toyota COROLLA
- Year
- 1982 - 1983
- Sales region
- U.S.A.
- Frame
- AE71
- grade
- DX
- body
- HT
- ENGINE
- 4AC
- TRANSMISSION
- ATM
- DESTINATION
- CND
- Model
- COROLLA
- From
- 08.1982
- To
- 07.1983
- Gear Shift Type
- 3FC
- No.of Doors
- 2D
- Vehicle Model
- Corolla
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35620A
|
35620A
35634-22060 Plate, Clutch (For Overdrive)[08.1982 - 07.1983] AE71..ATM T=1.8,NSK-WARNER |
35634-22060 |
US $34.42 |
||
|
35620A
|
35620A
35634-22090 Plate, Clutch (For Brake)[08.1979 - 07.1983] AE71,TE72..3FC AISIN CHEMICAL |
35634-22090 |
US $35.24 |
||
| replacement | |||||
|
35620A
|
35620A
35634-22060 Plate, Clutch (For Overdrive)[08.1979 - 07.1983] AE71,TE72..3FC AISIN CHEMICAL |
35634-22060 |
US $34.42 |
||
|
35620B
|
35620B
35677-22020 Disc, Clutch (For Overdrive)[08.1982 - 07.1983] AE71..ATM NSK-WARNER |
35677-22020 |
US $47.17 |
||
| replacement | |||||
|
35620B
|
35620B
35677-30160 Disc, Clutch (For Overdrive)[08.1982 - 07.1983] AE71..ATM NSK-WARNER |
35677-30160 |
from US $38.16 |
||
|
35620B
|
35620B
35677-22030 Disc, Clutch (For Brake)[08.1982 - 07.1983] AE71..3FC AISIN CHEMICAL |
35677-22030 |
US $42.52 |
||
| replacement | |||||
|
35620B
|
35620B
35677-30160 Disc, Clutch (For Overdrive)[08.1982 - 07.1983] AE71..3FC AISIN CHEMICAL |
35677-30160 |
from US $38.16 |
||
|
35620B
|
35620B
35677-22050 Disc, Clutch (For Brake)[07.1983 - 07.1983] AE71..3FC AISIN CHEMICAL |
35677-22050 |
US $36.84 |
||
| replacement | |||||
|
35620B
|
35620B
35677-30160 Disc, Clutch (For Overdrive)[07.1983 - 07.1983] AE71..3FC AISIN CHEMICAL |
35677-30160 |
from US $38.16 |
||
|
35620C
|
35620C
35675-22010
Flange, Overdrive Clutch
[08.1979 - 07.1983] AE71,TE72..ATM |
35675-22010 |
— | ||
| replacement | |||||
|
35620C
|
35620C
35675-22140
Flange, Overdrive Clutch
[08.1979 - 07.1983] AE71,TE72..ATM |
35675-22140 |
— | ||
|
35620D
|
35620D
90521-99139
Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
[08.1979 - 07.1983] AE71,TE72..ATM |
90521-99139 |
— | ||
|
35620R
|
35620R
35634-22060 Plate, Clutch (For Overdrive)[08.1979 - 07.1983] AE71,TE72..3FC NSK-WARNER |
35634-22060 |
US $34.42 |
||
|
35620R
|
35620R
35634-22090 Plate, Clutch (For Brake)[08.1979 - 07.1983] AE71,TE72..3FC AISIN CHEMICAL |
35634-22090 |
US $35.24 |
||
| replacement | |||||
|
35620R
|
35620R
35634-22060 Plate, Clutch (For Overdrive)[08.1979 - 07.1983] AE71,TE72..3FC AISIN CHEMICAL |
35634-22060 |
US $34.42 |
||
|
35620S
|
35620S
35677-22040 Disc, Clutch (For Rear Brake)[08.1979 - 07.1983] AE71,TE72..3FC |
35677-22040 |
US $40.48 |
||
| replacement | |||||
|
35620S
|
35620S
35677-30020 Disc, Clutch (For Rear Brake)[08.1979 - 07.1983] AE71,TE72..3FC |
35677-30020 |
US $42.81 |
||
|
35620S
|
35620S
35677-30020 Disc, Clutch (For Rear Brake)[07.1983 - 07.1983] AE71..3FC |
35677-30020 |
US $42.81 |
||
|
35620T
|
35620T
35675-22010
Flange, Overdrive Clutch
[08.1979 - 07.1983] AE71,TE72..3FC |
35675-22010 |
— | ||
| replacement | |||||
|
35620T
|
35620T
35675-22140
Flange, Overdrive Clutch
[08.1979 - 07.1983] AE71,TE72..3FC |
35675-22140 |
— | ||
|
35620U
|
35620U
90521-99139
Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
[08.1979 - 07.1983] AE71,TE72..3FC |
90521-99139 |
— | ||
|
35621
|
35621
35624-22010
Piston, Brake, No.1
[01.1981 - 07.1983] AE71,TE72..3FC |
35624-22010 |
— | ||
|
35621A
|
35621A
90301-99192 Ring, O (For Overdrive Direct Clutch Piston)[08.1979 - 07.1983] AE71,TE72..3FC |
90301-99192 |
US $12.80 |
||
|
35621B
|
35621B
90301-57188 Ring, O (For Underdrive Clutch Piston)[08.1979 - 07.1983] AE71,TE72..ATM |
90301-57188 |
US $10.08 |
||
| replacement | |||||
|
35621B
|
35621B
90301-56007 Ring, O (For Underdrive Clutch Piston)[08.1979 - 07.1983] AE71,TE72..ATM |
90301-56007 |
US $2.72 |
||
|
35621C
|
35621C
90501-10671 Spring, Compression (For Overdrive Direct Clutch)[08.1979 - 07.1983] AE71,TE72..ATM |
90501-10671 |
US $2.48 |
||
|
35621R
|
35621R
35621-30010
Piston, Brake, No.1
[08.1981 - 07.1983] AE71,TE72..3FC |
35621-30010 |
— | ||
|
35621S
|
35621S
90301-99007 Ring, O (For Brake Piston Outer)[08.1981 - 07.1983] AE71,TE72..3FC |
90301-99007 |
US $16.89 |
||
| replacement | |||||
|
35621S
|
35621S
90301-99107 Ring (For Rear Brake Piston Outer)[08.1981 - 07.1983] AE71,TE72..3FC |
90301-99107 |
US $2.62 |
||
|
35621T
|
35621T
90301-57188 Ring, O (For Underdrive Clutch Piston)[08.1979 - 07.1983] AE71,TE72..3FC |
90301-57188 |
US $10.08 |
||
| replacement | |||||
|
35621T
|
35621T
90301-56007 Ring, O (For Underdrive Clutch Piston)[08.1979 - 07.1983] AE71,TE72..3FC |
90301-56007 |
US $2.72 |
||
|
35621U
|
35621U
90501-10671 Spring, Compression (For Overdrive Direct Clutch)[08.1979 - 07.1983] AE71,TE72..3FC |
90501-10671 |
US $2.48 |
||
|
35627
|
35627
35627-22010 Seat, Brake Return Spring[08.1979 - 07.1983] AE71,TE72..ATM |
35627-22010 |
US $7.13 |
||
|
35627A
|
35627A
90520-52262 Ring, Shaft Snap (For Underdrive Return Spring)[08.1979 - 07.1983] AE71,TE72..ATM |
90520-52262 |
US $2.80 |
||
|
35627R
|
35627R
35627-22010 Seat, Brake Return Spring[08.1979 - 07.1983] AE71,TE72..3FC |
35627-22010 |
US $7.13 |
||
|
35627S
|
35627S
90520-52262 Ring, Shaft Snap (For Underdrive Return Spring)[08.1979 - 07.1983] AE71,TE72..3FC |
90520-52262 |
US $2.80 |
||
|
35662
|
35662
35662-22011 Hub, Brake[08.1979 - 07.1983] AE71,TE72..3FC |
35662-22011 |
US $148.51 |
||
| replacement | |||||
|
35662
|
35662
35662-30010 Hub, Brake[08.1979 - 07.1983] AE71,TE72..3FC |
35662-30010 |
US $93.18 |
||
|
35709
|
35709
35709-12011 Support Sub-Assy, Center[08.1981 - 07.1983] AE71,TE72..3FC |
35709-12011 |
US $352.35 |
||
|
35709C
|
35709C
35617-16010 Ring, Oil Seal (For Overdrive Case)[08.1981 - 07.1983] AE71,TE72..ATM |
35617-16010 |
US $16.42 |
||
|
35790
|
35790
35791-22010 Clutch Assy, 1 Way[08.1979 - 07.1983] AE71,TE72..3FC |
35791-22010 |
US $147.06 |
||
| replacement | |||||
|
35790
|
35790
35791-30020 Clutch, 1Way, No.1(For Overdrive)[08.1979 - 07.1983] AE71,TE72..3FC |
35791-30020 |
US $155.79 |
||
|
35793
|
35793
35793-22011
Retainer, 1 Way Clutch
[08.1979 - 07.1983] AE71,TE72..3FC |
35793-22011 |
— | ||
|
9010908073
|
9010908073
90109-08073 Bolt (For Front Oil Pump Setting) |
90109-08073 |
US $3.93 |
||
|
9454200800
|
9454200800
94542-00800 New Genuine Part |
94542-00800 |
US $2.18 |
||
