Injection Pump Body ([08.1983 - 08.1985] (8308-8508)1CLC) Diagram Toyota COROLLA
- Year
- 1983 - 1984
- Sales region
- Europe
- Frame
- CE80
- grade
- STD
- body
- SED
- ENGINE
- 1CLC
- TRANSMISSION
- MTM
- DESTINATION
- USA
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 08.1983
- To
- 08.1984
- Gear Shift Type
- 4F
- Vehicle Model
- Corolla
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
22119
|
22119
22119-77020
Washer, Air Bleeder Nipple
[08.1983 - 08.1985] 1CLC..CE80 |
22119-77020 |
— | ||
| replacement | |||||
|
22119
|
22119
90201-12109 Washer, Air Bleeder Nipple[08.1983 - 08.1985] 1CLC..CE80 |
90201-12109 |
from US $1.33 |
||
|
22129
|
22129
22129-64400
Plug, Screw
[08.1983 - 08.1985] 1CLC..CE80 |
22129-64400 |
— | ||
|
22129A
|
22129A
22119-77020
Washer, Air Bleeder Nipple
[08.1983 - 08.1984] 1CLC..CE80 |
22119-77020 |
— | ||
| replacement | |||||
|
22129A
|
22129A
90201-12109 Washer, Air Bleeder Nipple[08.1983 - 08.1984] 1CLC..CE80 |
90201-12109 |
from US $1.33 |
||
|
22129A
|
22129A
22689-54290
Washer, Air Bleeder Nipple(For Screw Plug)
[08.1984 - 08.1985] 1CLC..CE80 |
22689-54290 |
— | ||
|
22160
|
22160
22160-64010
Screw Sub-Assy, Overflow
[08.1983 - 08.1985] 1CLC..CE80 |
22160-64010 |
— | ||
|
22193
|
22193
22193-54121
Ring, O(For Lever Connecting Pin)
[08.1983 - 08.1985] 1CLC..CE80 |
22193-54121 |
— | ||
| replacement | |||||
|
22193
|
22193
22193-55031
Ring, O(For Lever Connecting Pin)
[08.1983 - 08.1985] 1CLC..CE80 |
22193-55031 |
— | ||
|
22305A
|
22305A
22305-64010
Idle-Up Sub-Assy
[08.1983 - 08.1985] 1CLC..CE80 |
22305-64010 |
— | ||
|
22308B
|
22308B
22308-54120
Lever Sub-Assy, Control
[08.1983 - 08.1985] 1CLC..CE80 |
22308-54120 |
— | ||
|
22321A
|
22321A
22321-64400
Rod, Push
[08.1983 - 10.1984] 1CLC..CE80 |
22321-64400 |
— | ||
|
22322A
|
22322A
22322-64350
Spring, Return
[08.1983 - 08.1985] 1CLC..CE80 |
22322-64350 |
— | ||
|
22322B
|
22322B
22322-64011
Spring, Return(Inner)
[08.1983 - 08.1985] 1CLC..CE80 |
22322-64011 |
— | ||
|
22327A
|
22327A
22327-54120
Spring(For Bellows)
[08.1983 - 08.1985] 1CLC..CE80 |
22327-54120 |
— | ||
|
22327C
|
22327C
22327-64400
Spring(For Bellows)
[08.1983 - 08.1985] 1CLC..CE80 |
22327-64400 |
— | ||
|
22338A
|
22338A
22338-54120
Pin, Lever Connecting
[08.1983 - 08.1985] 1CLC..CE80 |
22338-54120 |
— | ||
|
22348A
|
22348A
22348-64400
Bushing, Guide
[08.1983 - 08.1984] 1CLC..CE80 |
22348-64400 |
— | ||
|
22348A
|
22348A
22348-64680
Bushing, Guide
[08.1984 - 08.1985] 1CLC..CE80 |
22348-64680 |
— | ||
|
22348B
|
22348B
22348-54121
Bushing, Guide
[08.1983 - 08.1985] 1CLC..CE80 |
22348-54121 |
— | ||
|
22378
|
22378
22378-76010
Washer, Drain Screw
[08.1983 - 08.1985] 1CLC..CE80 |
22378-76010 |
— | ||
| replacement | |||||
|
22378
|
22378
22113-77090
Washer, Drain Screw
[08.1983 - 08.1985] 1CLC..CE80 |
22113-77090 |
— | ||
|
22526A
|
22526A
22526-54120
Pin, Lever Support
[08.1983 - 08.1985] 1CLC..CE80 |
22526-54120 |
— | ||
|
22680D
|
22680D
22680-64400
Bellows Assy, Pneumatic
[08.1983 - 08.1985] 1CLC..CE80 |
22680-64400 |
— | ||
|
22680E
|
22680E
90099-01473
Washer(For Guide Bushing)
[08.1983 - 08.1985] 1CLC..CE80 |
90099-01473 |
— | ||
|
22681
|
22681
22681-64400
Bellows Sub-Assy, Pneumatic
[08.1983 - 08.1985] 1CLC..CE80 |
22681-64400 |
— | ||
|
22686A
|
22686A
22682-64400
Cover, Pneumatic Bellows
[08.1983 - 08.1985] 1CLC..CE80 |
22682-64400 |
— | ||
|
22686B
|
22686B
90099-14057
Ring, O(For Bellows Cover)
[08.1983 - 08.1985] 1CLC..CE80 |
90099-14057 |
— | ||
|
22701
|
22701
22701-64400
Lever Sub-Assy, Adjusting
[08.1983 - 08.1984] 1CLC..CE80..MTM MARK "85" |
22701-64400 |
— | ||
| replacement | |||||
|
22701
|
22701
22701-64450
Lever Sub-Assy, Adjusting
[08.1983 - 08.1984] 1CLC..CE80..MTM MARK "85" |
22701-64450 |
— | ||
|
22701
|
22701
22701-64401
Lever Sub-Assy, Adjusting
[08.1983 - 08.1984] 1CLC..CE80..MTM MARK "86" |
22701-64401 |
— | ||
| replacement | |||||
|
22701
|
22701
22701-64451
Lever Sub-Assy, Adjusting
[08.1983 - 08.1984] 1CLC..CE80..MTM MARK "86" |
22701-64451 |
— | ||
|
22701
|
22701
22701-64440
Lever Sub-Assy, Adjusting
[08.1984 - 08.1985] 1CLC..CE80..5F MARK"83" |
22701-64440 |
— | ||
|
22701
|
22701
22701-64441
Lever Sub-Assy, Adjusting
[08.1984 - 08.1985] 1CLC..CE80..5F MARK"84" |
22701-64441 |
— | ||
|
22703A
|
22703A
22703-64400
Cover Sub-Assy, Governor
[08.1983 - 10.1984] 1CLC..CE80 |
22703-64400 |
— | ||
| replacements | |||||
|
22703A
|
22703A
22703-54412
Cover Sub-Assy, Governor
[08.1983 - 10.1984] 1CLC..CE80 |
22703-54412 |
— | ||
|
22703A
|
22703A
22777-54291
Cap, Rubber(For Altitude Compensating Timer Advancer)
[08.1983 - 10.1984] 1CLC..CE80 |
22777-54291 |
— | ||
|
22712
|
22712
22775-77121 Nut, Rock[08.1983 - 08.1985] 1CLC..CE80 |
22775-77121 |
US $3.26 |
||
|
22728
|
22728
22728-64010
Guide, Return Spring
[08.1983 - 08.1985] 1CLC..CE80 |
22728-64010 |
— | ||
|
22739A
|
22739A
22739-54120
Bolt, Governor Link Support
[08.1983 - 08.1985] 1CLC..CE80 |
22739-54120 |
— | ||
|
22774
|
22774
22774-54010
Gasket, Governor Cover
[08.1983 - 08.1985] 1CLC..CE80 |
22774-54010 |
— | ||
| replacement | |||||
|
22774
|
22774
22774-54270 Gasket, Governor Cover[08.1983 - 08.1985] 1CLC..CE80 |
22774-54270 |
from US $3.14 |
||
|
22776
|
22776
22776-54110 Screw, Smoke Set Adjusting[08.1983 - 08.1985] 1CLC..CE80 |
22776-54110 |
from US $4.72 |
||
|
22776A
|
22776A
90099-14047
Ring, O(For Smoke Set Screw)
[08.1983 - 08.1985] 1CLC..CE80 |
90099-14047 |
— | ||
| replacement | |||||
|
22776A
|
22776A
22193-54771 Ring, O(For Smoke Set Screw)[08.1983 - 08.1985] 1CLC..CE80 |
22193-54771 |
US $1.33 |
||
|
22777
|
22777
22777-54120
Cap, Rubber(For Bellows)
[08.1983 - 10.1984] 1CLC..CE80 |
22777-54120 |
— | ||
|
22777B
|
22777B
22777-64410
Cap, Rubber(For Bellows)
[08.1983 - 08.1985] 1CLC..CE80 |
22777-64410 |
— | ||
|
2217264150
|
2217264150
22172-64150
Clip, Connector Support, Solenoid
|
22172-64150 |
— | ||
|
2239554010
|
2239554010
22395-54010
Bolt, Socket(For Injection Pump Governor Cover)
|
22395-54010 |
— | ||
|
2272254120
|
2272254120
22722-54120
Nut, Governor Shaft Rock
|
22722-54120 |
— | ||
|
2277754130
|
2277754130
22777-54130
Cap, Rubber(For Bellows)
|
22777-54130 |
— | ||
|
9009120610
|
9009120610
90091-20610
New Genuine Part
|
90091-20610 |
— | ||
|
9009120611
|
9009120611
90091-20611
New Genuine Part
|
90091-20611 |
— | ||
|
9009300802
|
9009300802
90093-00802
Washer, Plate(For Connecting Pin)
|
90093-00802 |
— | ||
|
9009904953
|
9009904953
90099-04953
New Genuine Part
|
90099-04953 |
— | ||
|
9009905140
|
9009905140
90099-05140
New Genuine Part
|
90099-05140 |
— | ||
|
9009905156
|
9009905156
90099-05156
New Genuine Part
|
90099-05156 |
— | ||
|
9331914008
|
9331914008
93319-14008 SCREW |
93319-14008 |
from US $0.80 |
||
|
9338116012
|
9338116012
93381-16012 Screw |
93381-16012 |
US $2.24 |
||
|
9338516012
|
9338516012
93385-16012 New Genuine Part |
93385-16012 |
US $1.02 |
||
|
9411040600
|
9411040600
94110-40600 Nut, Rock |
94110-40600 |
from US $0.66 |
||
|
9451100600
|
9451100600
94511-00600 Washer, Lock, No.2 |
94511-00600 |
US $1.92 |
||
