Switch & Relay & Computer ([11.2000 - 08.2003] ENGINE & TRANSMISSION (0011-0308)ACU2#) Diagram Toyota HIGHLANDER/ KLUGER
- Year
- 2000 - 2007
- Sales region
- U.S.A.
- Frame
- ACU20
- body
- WG
- ENGINE
- 2AZFE
- Model
- HIGHLANDER
- From
- 11.2000
- To
- 05.2007
- Gear Shift Type
- 4FC
- Seating Capacity
- 05S
- Vehicle Model
- Highlander
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[05.2002 - 08.2003] ACU2#,MCU2# (L),DENSO |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[11.2000 - 08.2003] ACU2#,MCU2# (J),DENSO |
83530-28020 |
US $29.94 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [11.2000 - 08.2003] ACU2#,MCU2# (J),DENSO |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[11.2000 - 08.2003] ACU2#,MCU2# (J),DENSO |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [11.2000 - 08.2003] ACU2#,MCU2# (J),YAZAKI |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-AA011 Switch Assy, Oil Pressure (For Engine)[01.2003 - 08.2003] ACU2#,MCU2# (L),FASCO |
83530-AA011 |
US $14.56 |
||
| replacement | |||||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[01.2003 - 08.2003] ACU2#,MCU2# (L),FASCO |
83530-0E010 |
from US $51.25 |
||
|
84540
|
84540
84540-12230 Switch Assy, Neutral Start[11.2000 - 02.2002] ACU2#,MCU2# |
84540-12230 |
US $336.34 |
||
| replacement | |||||
|
84540
|
84540
84540-32110 Switch Assy, Neutral Start[11.2000 - 02.2002] ACU2#,MCU2# |
84540-32110 |
from US $159 |
||
|
84540
|
84540
84540-32110 Switch Assy, Neutral Start[02.2002 - 08.2003] ACU2#,MCU2# |
84540-32110 |
from US $159 |
||
|
84540
|
84540
84540-48010 Switch Assy, Neutral Start[08.2003 - 05.2007] ACU2#; MCU2# (J) |
84540-48010 |
US $159 |
||
|
89465
|
89465
89465-48060 Sensor, OxygenOXYGEN [11.2000 - 08.2003] ACU2# EX. MANIFOLD 2,3SIDE |
89465-48060 |
US $149.97 |
||
|
89465
|
89465
89465-48070 Sensor, OxygenOXYGEN [11.2000 - 08.2003] ACU2# EX. MANIFOLD 1,4SIDE |
89465-48070 |
from US $149.97 |
||
|
89467B
|
89467B
89467-48020 Sensor, Air Fuel RatioAIR FUEL RATIO [11.2000 - 08.2003] ACU2# EX. MANIFOLD 1,4SIDE |
89467-48020 |
US $209.66 |
||
|
89467B
|
89467B
89467-48030 Sensor, Air Fuel RatioAIR FUEL RATIO [11.2000 - 08.2003] ACU2# EX. MANIFOLD 2,3SIDE |
89467-48030 |
US $209.66 |
||
|
89467B
|
89467B
89467-48070
Sensor, Air Fuel Ratio
[08.2003 -] ACU2# |
89467-48070 |
— | ||
|
89615
|
89615
89615-20090 Sensor, Knock Control[08.2003 -] ACU2# |
89615-20090 |
from US $36.02 |
||
|
89615
|
89615
89615-30080 Sensor, Knock Control[11.2000 - 04.2001] ACU2# MATSUSHITA |
89615-30080 |
from US $131.59 |
||
|
89615
|
89615
89615-32030 Sensor, Knock Control[11.2000 - 04.2001] ACU2# DENSO |
89615-32030 |
from US $198.14 |
||
|
89615
|
89615
89615-44010 Sensor, Knock Control[04.2001 - 08.2003] ACU2# |
89615-44010 |
US $227.14 |
||
|
8271528830
|
8271528830
82715-28830 Bracket,wiring Harness Clamp |
82715-28830 |
US $5.53 |
||
|
8761635010
|
8761635010
87616-35010 Clamp, Cooling Unit Case |
87616-35010 |
from US $4.91 |
||
|
8761642020
|
8761642020
87616-42020 Clamp, Cooling Unit Case |
87616-42020 |
US $4.16 |
||
|
8761648010
|
8761648010
87616-48010 Clamp, Cooling Unit Case |
87616-48010 |
US $8.30 |
||
|
9017908025
|
9017908025
90179-08025 Nut, Cap(For Cylinder Head Cover) |
90179-08025 |
from US $0.92 |
||
|
9165140625
|
9165140625
91651-40625 New Genuine Part |
91651-40625 |
US $1.12 |
||
