Switch & Relay & Computer ([01.2012 - ] ENGINE & TRANSMISSION (1201- )URJ202) Diagram Toyota LAND CRUISER
- Year
- 2012 - 2018
- Sales region
- Europe
- Frame
- URJ202
- grade
- VX
- ENGINE
- 1URFE
- Model
- LAND CRUISER 200
- From
- 01.2012
- Seating Capacity
- 05S
- Vehicle Model
- Land Cruiser
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83520
|
83520
83520-60050
Gage Assy,oil Pressure Sender
[01.2012 - 07.2015] URJ202,VDJ200 |
83520-60050 |
— | ||
| replacement | |||||
|
83520
|
83520
83520-60051 Gage Assy,oil Pressure Sender[01.2012 - 07.2015] URJ202,VDJ200 |
83520-60051 |
from US $37.54 |
||
|
83520
|
83520
83520-60051 Gage Assy,oil Pressure Sender[08.2015 -] VDJ200..RHD..VX;URJ202,VDJ200..LHD |
83520-60051 |
from US $37.54 |
||
|
84540
|
84540
84540-60050 Switch Assy, Neutral StartNEUTRAL START [01.2012 - 08.2015] URJ202 |
84540-60050 |
from US $112.48 |
||
|
89465
|
89465
89465-60370 Sensor, Oxygen[01.2012 - 08.2015] URJ202 |
89465-60370 |
from US $139.12 |
||
|
89465A
|
89465A
89465-36040 Sensor, Oxygen No.2[01.2012 - 08.2015] URJ202 |
89465-36040 |
from US $115.44 |
||
|
89467B
|
89467B
89467-22030 Sensor, Air Fuel RatioAIR FUEL RATIO [08.2015 -] URJ202 |
89467-22030 |
from US $146.52 |
||
|
89467B
|
89467B
89467-34030 Sensor, Air Fuel Ratio[01.2012 - 08.2015] URJ202 |
89467-34030 |
from US $195.84 |
||
|
89491
|
89491
89491-60160 Sensor, Engine Oil Level[01.2012 - 08.2015] URJ202 |
89491-60160 |
US $103.08 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[01.2012 - 08.2015] URJ202,VDJ200 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[01.2012 - 08.2015] URJ202 |
89615-20090 |
from US $36.02 |
||
|
90119A0406
|
90119A0406
90119-A0406
New Genuine Part
|
90119-A0406 |
— | ||
|
91511B0830
|
91511B0830
91511-B0830 Bolt Or Ring, Exhaust Pipe Front (For Front) |
91511-B0830 |
from US $1.01 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.94 |
||
|
8271560K80
|
8271560K80
82715-60K80
Bracket,wiring Harness Clamp
|
82715-60K80 |
— | ||
|
8271560L00
|
8271560L00
82715-60L00
Bracket,wiring Harness Clamp
|
82715-60L00 |
— | ||
|
8271560R30
|
8271560R30
82715-60R30
Bracket,wiring Harness Clamp
|
82715-60R30 |
— | ||
|
8271560Y50
|
8271560Y50
82715-60Y50 Bracket,wiring Harness Clamp |
82715-60Y50 |
US $9.03 |
||
|
9011908C62
|
9011908C62
90119-08C62 New Genuine Part |
90119-08C62 |
US $1.28 |
||
|
9167180612
|
9167180612
91671-80612 Bolt |
91671-80612 |
from US $0.68 |
||
|
9167180816
|
9167180816
91671-80816 Bolt (For Transmission Control Cable Bracket) |
91671-80816 |
from US $0.88 |
||
