Shift Lever & Retainer ([06.1989 - ] (8906- )5F) Diagram Toyota LEXUS ES
- Year
- 1989 - 1991
- Sales region
- U.S.A.
- Frame
- VZV21
- body
- HT
- ENGINE
- 2VZFE
- DESTINATION
- USA
- Model
- ES250
- From
- 06.1989
- To
- 07.1991
- Gear Shift Type
- 5F
- Vehicle Model
- ES250
- Fuel Induction
- HTWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
33524B
|
33524B
33524-32010 Bracket, Control Cable[06.1989 - 07.1991] VZV21..5F |
33524-32010 |
US $19.66 |
||
|
33527B
|
33527B
90389-10009 Bush (For Shift & Select Lever)[06.1989 - 07.1991] VZV21..5F |
90389-10009 |
from US $9.92 |
||
|
33534E
|
33534E
33534-20020
Crank, Selecting Bell, No.2
[06.1989 - 06.1991] VZV21..5F |
33534-20020 |
— | ||
|
33534F
|
33534F
90386-12022 Bush (For Selecting Bellcrank No.1)[06.1989 - 06.1991] VZV21..5F |
90386-12022 |
US $2.08 |
||
|
33534G
|
33534G
90201-08028 Washer, Plate (For Selecting Bellcrank No.2)[06.1989 - 06.1991] VZV21..5F |
90201-08028 |
US $0.96 |
||
|
33557A
|
33557A
33557-32010 Cover, Selecting Bellcrank Dust, No.1[06.1989 - 06.1991] VZV21..5F |
33557-32010 |
from US $4.48 |
||
|
33558
|
33558
33558-12010
Cover, Selecting Bellcrank Dust, No.2
[06.1989 - 06.1991] VZV21..5F |
33558-12010 |
— | ||
|
33574A
|
33574A
33574-32110
Retainer, Shift Cable Grommet, No.1
[06.1989 - 07.1991] VZV21..5F |
33574-32110 |
— | ||
|
33574B
|
33574B
33574-32090 Retainer, Shift Cable Grommet, No.2[06.1989 - 07.1991] VZV21..5F |
33574-32090 |
US $6.84 |
||
|
33608
|
33608
33608-20010
Support Sub-Assy, Selecting Bellcrank
[06.1989 - 06.1991] VZV21..5F |
33608-20010 |
— | ||
|
33821
|
33821
33821-32182 Cable Transmission Control Shift (For Floor Shift)[06.1989 - 09.1990] VZV21..5F |
33821-32182 |
US $202.38 |
||
| replacement | |||||
|
33821
|
33821
33821-32183 Cable Transmission Control Shift (For Floor Shift)[06.1989 - 09.1990] VZV21..5F |
33821-32183 |
US $202.38 |
||
|
33821
|
33821
33821-32183 Cable Transmission Control Shift (For Floor Shift)[09.1990 - 07.1991] VZV21..5F |
33821-32183 |
US $202.38 |
||
|
33821A
|
33821A
90480-01366
Grommet, No.1 (For Transmission Control Cable)
[06.1989 - 07.1991] VZV21..5F |
90480-01366 |
— | ||
|
33821C
|
33821C
90201-08267 Washer, Plate (For Transfer Control Cable)[06.1989 - 07.1991] VZV21..5F OD=28,TRANSAXLE SIDE |
90201-08267 |
from US $0.92 |
||
|
33821C
|
33821C
90201-10042 Washer, Plate (For Transfer Control Cable)[06.1989 - 07.1991] VZV21..5F SHIFT LEVER SIDE |
90201-10042 |
US $1.44 |
||
|
33822
|
33822
33822-32102 Cable Transmission Control Select (For Floor Shift)[06.1989 - 09.1990] VZV21..5F |
33822-32102 |
US $200.93 |
||
| replacement | |||||
|
33822
|
33822
33822-32103 Cable Transmission Control Select (For Floor Shift)[06.1989 - 09.1990] VZV21..5F |
33822-32103 |
US $202.38 |
||
|
33822
|
33822
33822-32103 Cable Transmission Control Select (For Floor Shift)[09.1990 - 07.1991] VZV21..5F |
33822-32103 |
US $202.38 |
||
|
9011910216
|
9011910216
90119-10216 Bolt (For Control Shaft Cover) |
90119-10216 |
US $2.72 |
||
|
9046814016
|
9046814016
90468-14016 CLIP |
90468-14016 |
from US $1.17 |
||
|
9046814017
|
9046814017
90468-14017 Clip, No.2(For Parking Brake) |
90468-14017 |
from US $0.90 |
||
|
9046814020
|
9046814020
90468-14020 New Genuine Part |
90468-14020 |
US $2.48 |
||
|
9161160820
|
9161160820
91611-60820
Bolt(For Transaxle & Engine Setting)
|
91611-60820 |
— | ||
| replacement | |||||
|
9161160820
|
9161160820
91611-G0820 Bolt |
91611-G0820 |
from US $1.31 |
||
|
9165640616
|
9165640616
91656-40616
Bolt
|
91656-40616 |
— | ||
| replacement | |||||
|
9165640616
|
9165640616
91651-60614 Bolt |
91651-60614 |
US $1.12 |
||
|
9356015020
|
9356015020
93560-15020 SCREW |
93560-15020 |
from US $0.52 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.90 |
||
|
9451100800
|
9451100800
94511-00800 WASHERSPRING |
94511-00800 |
from US $1.60 |
||
