Switch & Relay & Computer ([02.2006 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0602- )) Diagram Toyota LEXUS GS
- Year
- 2006 - 2011
- Sales region
- Japan
- Frame
- GWS191
- ENGINE
- 2GRFSE
- TRANSMISSION
- ATM
- Model
- GS450 Hybrid
- From
- 02.2006
- To
- 12.2011
- Vehicle Model
- GS450 Hybrid
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[02.2006 - 09.2007] GWS191 ＤＥＮＳＯ |
83530-28020 |
US $29.94 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [02.2006 - 09.2007] GWS191 ＤＥＮＳＯ |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[02.2006 - 09.2007] GWS191 ＤＥＮＳＯ |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [02.2006 - 09.2007] GWS191 ＹＡＺＡＫＩ |
83530-60020 |
from US $25.21 |
||
|
83531C
|
83531C
83531-30011 Switch, Oil Pressure, (Pb1)[02.2006 - 09.2007] GWS191 |
83531-30011 |
US $10.66 |
||
|
83531D
|
83531D
83531-30011 Switch, Oil Pressure, (Pb1)[02.2006 - 09.2007] GWS191 |
83531-30011 |
US $10.66 |
||
|
83531E
|
83531E
83531-30021 Switch, Oil Pressure, (Pb3)[02.2006 - 09.2007] GWS191 |
83531-30021 |
US $14.56 |
||
| replacement | |||||
|
83531E
|
83531E
83531-30023 Switch, Oil Pressure, (Pb3)[02.2006 - 09.2007] GWS191 |
83531-30023 |
US $10.66 |
||
|
89465
|
89465
89465-30730 Sensor, Oxygen[02.2006 - 09.2007] GWS191 |
89465-30730 |
from US $139.12 |
||
|
89467B
|
89467B
89467-30010 Sensor, Air Fuel Ratio[02.2006 - 09.2007] GWS191 右側 |
89467-30010 |
from US $218.61 |
||
|
89467B
|
89467B
89467-30020 Sensor, Air Fuel Ratio[02.2006 - 09.2007] GWS191 左側 |
89467-30020 |
US $224.64 |
||
|
89491
|
89491
89491-30060
Sensor, Engine Oil Level
[02.2006 - 09.2007] GWS191 |
89491-30060 |
— | ||
| replacement | |||||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[02.2006 - 09.2007] GWS191 |
89491-30061 |
from US $140.60 |
||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[09.2011 - 12.2011] GWS191 |
89491-30061 |
from US $140.60 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[02.2006 - 09.2007] GWS191 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[02.2006 - 09.2007] GWS191 |
89615-20090 |
from US $36.02 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.84 |
||
|
827112B660
|
827112B660
82711-2B660 Clamp, Wiring Harness |
82711-2B660 |
US $3.04 |
||
|
8271135060
|
8271135060
82711-35060 Clamp, Wiring Harness |
82711-35060 |
US $3.84 |
||
|
9155180830
|
9155180830
91551-80830 Bolt, Compressor, No.2 |
91551-80830 |
from US $0.92 |
||
