Switch & Relay & Computer ([08.2005 - 09.2007] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0508-0709)UZS190) Diagram Toyota LEXUS GS
- Year
- 2005 - 2007
- Sales region
- Japan
- Frame
- UZS190
- ENGINE
- 3UZFE
- TRANSMISSION
- ATM
- Model
- GS430
- From
- 08.2005
- To
- 09.2007
- Vehicle Model
- GS430
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[08.2005 - 09.2007] GRS19#,UZS190 |
83530-28020 |
US $29.94 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [08.2005 - 09.2007] GRS19#,UZS190 |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[08.2005 - 09.2007] GRS19#,UZS190 |
83530-0E010 |
from US $51.25 |
||
|
84540
|
84540
84540-30320 Switch Assy, Neutral Start[08.2005 - 09.2007] UZS190 |
84540-30320 |
US $174.24 |
||
|
89465
|
89465
89465-50120 Sensor, Oxygen[08.2005 - 09.2007] UZS190 左側 |
89465-50120 |
from US $168.48 |
||
|
89465
|
89465
89465-50130 Sensor, Oxygen[08.2005 - 09.2007] UZS190 右側 |
89465-50130 |
from US $168.48 |
||
|
89465A
|
89465A
89465-30740 Sensor, Oxygen No.2[08.2005 - 09.2007] UZS190 |
89465-30740 |
from US $152.88 |
||
|
89491
|
89491
89491-50030 Sensor, Engine Oil Level[08.2005 - 09.2007] UZS190 |
89491-50030 |
from US $165.60 |
||
|
89491A
|
89491A
90430-27001 Gasket, Engine Oil Level Sensor[08.2005 - 09.2007] UZS190 |
90430-27001 |
from US $1.09 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[08.2005 - 09.2007] GRS19#,UZS190 |
89615-20090 |
from US $36.02 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.84 |
||
|
91621B0816
|
91621B0816
91621-B0816 BOLT WWASHER |
91621-B0816 |
from US $0.90 |
||
|
91621J0612
|
91621J0612
91621-J0612 BOLT W-WASHER |
91621-J0612 |
from US $0.70 |
||
|
8271550480
|
8271550480
82715-50480 Bracket,wiring Harness Clamp |
82715-50480 |
US $3.06 |
||
|
8271550500
|
8271550500
82715-50500 Bracket,wiring Harness Clamp |
82715-50500 |
US $3.20 |
||
|
9012608039
|
9012608039
90126-08039 Bolt, Stud(For Oil Pan) |
90126-08039 |
US $3.84 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.84 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
