Switch & Relay & Computer ([09.2012 - ] ENGINE & TRANSMISSION (1209- )) Diagram Toyota LEXUS LS
- Year
- 2012 - 2018
- Sales region
- U.S.A.
- Frame
- UVF46
- body
- SED
- ENGINE
- 2URFSE
- TRANSMISSION
- ATM
- Model
- LS600L Hybrid
- From
- 09.2012
- Gear Shift Type
- CVFC
- No.of Doors
- 4D
- Vehicle Model
- LS600L Hybrid
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [09.2012 -] UVF46 |
83530-60020 |
from US $25.55 |
||
|
83531C
|
83531C
83531-30011 Switch, Oil Pressure, (Pb1)[09.2012 -] UVF46 MARK = BLUE |
83531-30011 |
US $10.66 |
||
|
83531D
|
83531D
83531-30011 Switch, Oil Pressure, (Pb1)[09.2012 -] UVF46 MARK = BLUE |
83531-30011 |
US $10.66 |
||
|
83531E
|
83531E
83531-30022
Switch, Oil Pressure, (Pb3)
[09.2012 - 07.2014] UVF46 MARK = PURPLE |
83531-30022 |
— | ||
| replacement | |||||
|
83531E
|
83531E
83531-30023 Switch, Oil Pressure, (Pb3)[09.2012 - 07.2014] UVF46 MARK = PURPLE |
83531-30023 |
US $10.66 |
||
|
83531E
|
83531E
83531-30023 Switch, Oil Pressure, (Pb3)[08.2014 -] UVF46 MARK = PURPLE |
83531-30023 |
US $10.66 |
||
|
89425
|
89425
89425-50040
Sensor, Exhaust Gas Temperature
[09.2012 -] UVF46 RH |
89425-50040 |
— | ||
|
89425
|
89425
89425-50050
Sensor, Exhaust Gas Temperature
[09.2012 -] UVF46 LH |
89425-50050 |
— | ||
|
89465
|
89465
89465-50170 Sensor, Oxygen[09.2012 - 09.2015] UVF46 |
89465-50170 |
from US $162.72 |
||
|
89465
|
89465
89465-50260
Sensor, Oxygen
[09.2015 -] UVF46 |
89465-50260 |
— | ||
|
89465A
|
89465A
89465-50200 Sensor, Oxygen No.2[09.2012 - 09.2015] UVF46 |
89465-50200 |
US $162.72 |
||
|
89465A
|
89465A
89465-50250
Sensor, Oxygen No.2
[09.2015 -] UVF46 |
89465-50250 |
— | ||
|
89467B
|
89467B
89467-53030 Sensor, Air Fuel Ratio[09.2012 - 09.2015] UVF46 |
89467-53030 |
US $199.31 |
||
|
89467B
|
89467B
89467-53060
Sensor, Air Fuel Ratio
[09.2015 -] UVF46 |
89467-53060 |
— | ||
|
89491
|
89491
89491-50050 Sensor, Engine Oil Level[09.2012 -] UVF46 |
89491-50050 |
US $96.10 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[09.2012 -] UVF46 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[09.2012 -] UVF46 |
89615-20090 |
from US $36.02 |
||
|
91511B0830
|
91511B0830
91511-B0830 Bolt Or Ring, Exhaust Pipe Front (For Front) |
91511-B0830 |
from US $0.98 |
||
|
91553A0810
|
91553A0810
91553-A0810 New Genuine Part |
91553-A0810 |
US $1.16 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.84 |
||
|
8271550A70
|
8271550A70
82715-50A70 Bracket,wiring Harness Clamp |
82715-50A70 |
US $3.20 |
||
|
8271550A80
|
8271550A80
82715-50A80 Bracket,wiring Harness Clamp |
82715-50A80 |
US $5.10 |
||
|
8271550A90
|
8271550A90
82715-50A90
Bracket,wiring Harness Clamp
|
82715-50A90 |
— | ||
|
8271550E20
|
8271550E20
82715-50E20
Bracket,wiring Harness Clamp
|
82715-50E20 |
— | ||
|
9167380614
|
9167380614
91673-80614 BOLT, FLANGE W/WASER |
91673-80614 |
US $0.96 |
||
