Abs & Vsc ([08.1988 - ] (8808- )GD,GDG,GT) Diagram Toyota MARK 2
- Year
- 1989 - 1993
- Sales region
- Japan
- Frame
- MX83
- grade
- GDG
- body
- SED
- ENGINE
- 7MGE
- TRANSMISSION
- ATM
- Model
- MARK 2
- From
- 08.1989
- To
- 02.1993
- Gear Shift Type
- 4FC
- Vehicle Model
- MARK 2
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35517A
|
35517A
35517-30010 Plate, Transmission Wire Lock[08.1988 - 02.1993] JZX81;GX81,MX83..GDG |
35517-30010 |
US $4.37 |
||
|
82125C
|
82125C
82125-14050 Wire, Transmission[08.1988 - 05.1992] JZX81,MX83..TWC;GX81..4FC..(SPC,TWC,TWT) |
82125-14050 |
US $36.84 |
||
|
89544
|
89544
89544-30010
Sensor, Skid Control
[08.1988 - 04.1993] GX81,JZX81,MX83..4FC..(SPC,TWC,TWT) |
89544-30010 |
— | ||
|
89544A
|
89544A
90301-11008 Ring,o (For Speedometer Driven Hole Cover)[08.1988 - 12.1995] GX81,JZX81,MX83..4FC..(GD,GDG,GT) |
90301-11008 |
from US $0.92 |
||
|
89548
|
89548
89548-14010 Rotor, Skid Control Sensor[08.1988 - 02.1993] GX81,JZX81,MX83..4FC..(SPC,TWC,TWT) |
89548-14010 |
US $45.72 |
||
|
89548A
|
89548A
90280-03005 Key, Oil Pump Drive Shaft[08.1988 - 12.1995] GX81,JZX81,MX83..4FC..(GD,GDG,GT) |
90280-03005 |
US $1.05 |
||
|
8271112200
|
8271112200
82711-12200 Clamp (For Fuel Lid Lock Control Cable) |
82711-12200 |
from US $1.62 |
||
|
9010508116
|
9010508116
90105-08116 New Genuine Part |
90105-08116 |
US $2.18 |
||
|
9161160616
|
9161160616
91611-60616
Bolt(For Transaxle Case Receiver)
|
91611-60616 |
— | ||
| replacement | |||||
|
9161160616
|
9161160616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.88 |
||
|
9165140820
|
9165140820
91651-40820 Bolt |
91651-40820 |
from US $1.06 |
||
