Disc Wheel & Wheel Cap ([11.2010 - ] (1011- )) Diagram Toyota VERSO
- Year
- 2010 - 2015
- Sales region
- Europe
- Frame
- NSP120
- grade
- LUNA
- ENGINE
- 1NRFE
- TRANSMISSION
- MTM
- Model
- VERSO-S
- From
- 11.2010
- To
- 04.2015
- Gear Shift Type
- 6F
- Vehicle Model
- VERSO-S
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04423
|
04423
04423-33030
Fitting Kit, Tire Pressure Monitor Or Balancer Valve
[05.2014 - 11.2014] NLP121,NSP120 |
04423-33030 |
— | ||
| replacement | |||||
|
04423
|
04423
04423-33060 Fitting Kit, Tire Pressure Monitor Or Balancer Valve[05.2014 - 11.2014] NLP121,NSP120 |
04423-33060 |
from US $4.48 |
||
|
04423
|
04423
04423-33060 Fitting Kit, Tire Pressure Monitor Or Balancer Valve[12.2014 - 04.2015] NLP121,NSP120 |
04423-33060 |
from US $4.48 |
||
|
42601
|
42601
42611-52720 Wheel, Disc[12.2013 - 05.2014] NSP120;NLP121..6F 15X5.5J,TYPE C:REFER ILLUST. |
42611-52720 |
US $135.41 |
||
| replacement | |||||
|
42601
|
42601
42611-52721 Wheel, Disc[12.2013 - 05.2014] NSP120;NLP121..6F 15X5.5J,TYPE C:REFER ILLUST. |
42611-52721 |
US $135.41 |
||
|
42601
|
42601
42611-52721 Wheel, Disc[05.2014 - 04.2015] NLP121,NSP120 15X5.5J,TYPE C:REFER ILLUST. |
42611-52721 |
US $135.41 |
||
|
42601
|
42601
42611-52730 Wheel, Disc[11.2010 - 05.2014] NLP121..6F..LUNA;NSP120..LHD..LUNA 16X5.5J,REAR WHEEL BRAKE-DISK(BUILT-IN)&TIRE & DISC WHEEL-185/60R16 5.5J ALUMINUM OS45,TYPE D:REFER ILLUST.; NLP121,NSP120..LUNA 16X5.5J,TIRE & DISC WHEEL-185/60R16 5.5J ALUMINUM OS45,TYPE D:REFER ILL |
42611-52730 |
US $497.95 |
||
|
42601
|
42601
42611-52740 Wheel, Disc[11.2010 - 12.2012] NSP120..LHD..TERRA 15X5.5J,RUSSIA SPEC&COLD SPEC & WITH(REAR HEATER DUCT),TYPE C:REFER ILLUST.; NSP120..LHD..LUNA 15X5.5J,RUSSIA SPEC&TIRE & DISC WHEEL-185/60R15 5.5J STEEL ROUGH ROAD SPEC,TYPE C: REFER ILLUST. |
42611-52740 |
US $142.69 |
||
|
42601
|
42601
42611-52A90
Wheel, Disc
[05.2014 - 04.2015] NLP121,NSP120..LHD..LUNA 16X5.5J,REAR WHEEL BRAKE-DISK(BUILT-IN)&TIRE & DISC WHEEL-185/60R16 5.5J ALUMINUM OS45,TYPE F:REFER ILLUST.; NLP121,NSP120..LUNA 16X5.5J,TIRE & DISC WHEEL-185/60R16 5.5J ALUMINUM OS45,TYPE F:REFER ILLUST. |
42611-52A90 |
— | ||
|
42601A
|
42601A
42611-20840 Wheel, Disc (For Spare)[11.2010 - 07.2012] NLP121,NSP120..LHD 16X4T,REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E:REFER ILLUST.; NSP120..LHD 16X4T,GUADELOUPE,MARTINIQUE,F.GUYANE SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E: REFER ILLUST.; NSP120..LHD 16X4T,UKRAINE SPEC&S |
42611-20840 |
US $135.41 |
||
| replacement | |||||
|
42601A
|
42601A
42611-20841 Wheel, Disc (For Spare)[11.2010 - 07.2012] NLP121,NSP120..LHD 16X4T,REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E:REFER ILLUST.; NSP120..LHD 16X4T,GUADELOUPE,MARTINIQUE,F.GUYANE SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E: REFER ILLUST.; NSP120..LHD 16X4T,UKRAINE SPEC&S |
42611-20841 |
US $135.41 |
||
|
42601A
|
42601A
42611-20A50 Wheel, Disc (For Spare)DISC (FOR SPARE) [07.2012 - 12.2012] NLP121,NSP120..LHD 16X4T,REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E:REFER ILLUST.; NSP120..LHD 16X4T,UKRAINE SPEC&SPARE TIRE-T135/70 D16 TEMPORARY,TYPE E:REFER ILLUST.; NLP121..6F;NSP120..LHD 16X4T,TURKEY SPEC&SPARE TIRE-T135 |
42611-20A50 |
US $133.20 |
||
|
42601C
|
42601C
90942-01007 Nut, Hub (For Axle)[11.2010 - 05.2014] NLP121,NSP120 TYPE A:REFER ILLUST. |
90942-01007 |
from US $2.07 |
||
|
42601C
|
42601C
90942-01033 Nut, Hub (For Axle)[11.2010 - 05.2014] NLP121,NSP120..LUNA TIRE & DISC WHEEL-185/60R16 5.5J ALUMINUM OS45,TYPE B:REFER ILLUST. |
90942-01033 |
from US $2.40 |
||
|
42607
|
42607
42607-42021 Valve Sub-Assy, Tire Pressure Monitor[05.2014 - 04.2015] NLP121,NSP120 |
42607-42021 |
from US $90.25 |
||
|
42611G
|
42611G
90942-05009 Valve (For Tubeless Tire)[11.2010 - 05.2014] NLP121,NSP120 |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611G
|
42611G
90080-94031 Valve (For Tubeless Tire)[11.2010 - 05.2014] NLP121,NSP120 |
90080-94031 |
US $1.66 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[11.2010 - 12.2012] NLP121,NSP120..LHD REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NSP120..LHD UKRAINE SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NLP121..6F;NSP120..LHD TURKEY SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NSP120..LHD RUSSIA SPEC&SPARE TIRE-T135/7 |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[11.2010 - 12.2012] NLP121,NSP120..LHD REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NSP120..LHD UKRAINE SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NLP121..6F;NSP120..LHD TURKEY SPEC&SPARE TIRE-T135/70 D16 TEMPORARY; NSP120..LHD RUSSIA SPEC&SPARE TIRE-T135/7 |
90080-94031 |
US $1.66 |
||
|
42611U
|
42611U
90942-05039 Cap, Tire ValveTIRE VALVE [05.2014 - 04.2015] NLP121,NSP120 |
90942-05039 |
from US $1.44 |
||
|
42652A
|
42652A
4265A-52010
Tire (For Spare)
[11.2010 - 12.2012] NLP121,NSP120..LHD T135/70D16,REUNION SPEC&SPARE TIRE-T135/70 D16 TEMPORARY |
4265A-52010 |
— | ||
