Steering pole Diagram Yamaha SJ700
- Model code
- GH73
- Engine Capacity
- 700
- Year
- 1994
- Sales region
- Europe (General) (999)
- Colour
- Dark Bluish Gray Metallic 2 (DBNM2; 004D)
- Stroke (2-stroke or 4-stroke)
- 2 stroke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
02
|
02
EW2-6491K-00-00 Bolt, Special |
EW2-6491K-00-00 |
from US $23.66 |
||
|
03
|
03
92990-05200-00 Washer, Plain |
92990-05200-00 |
from US $1.56 |
||
|
04
|
04
95780-05300-00 Nut, M5 X 0.8 Nylon Lock |
95780-05300-00 |
from US $1.84 |
||
|
05
|
05
EW2-61460-00-00
Cable Stopper Assembly
|
EW2-61460-00-00 |
— | ||
|
06
|
06
6E5-48538-00-00 Clamp, Cable |
6E5-48538-00-00 |
from US $9.78 |
||
|
07
|
07
91690-30012-00 Pin, Spring |
91690-30012-00 |
from US $2.69 |
||
|
08
|
08
90267-489U1-00 Rivet,blindYmus |
90267-489U1-00 |
from US $4.77 |
||
| replacement | |||||
|
08
|
08
90267-48938-00 Rivet (Eu0)Ymus |
90267-48938-00 |
from US $3.72 |
||
|
09
|
09
90601-20006-00 Band, Hose |
90601-20006-00 |
from US $2.27 |
||
| replacement | |||||
|
09
|
09
90601-20009-00 Band (Eu0) |
90601-20009-00 |
from US $2.27 |
||
|
10
|
10
EW2-61316-00-00 Plate, Stopper |
EW2-61316-00-00 |
US $10.48 |
||
|
11
|
11
97780-30312-00
Screw, O Head Tapping
|
97780-30312-00 |
— | ||
|
12
|
12
GH7-6142A-00-00 Steering Pad Comp |
GH7-6142A-00-00 |
US $144.63 |
||
|
13
|
13
EW2-64953-00-00
Plate A
|
EW2-64953-00-00 |
— | ||
|
14
|
14
90267-489U1-00 Rivet,blindYmus |
90267-489U1-00 |
from US $4.77 |
||
| replacement | |||||
|
14
|
14
90267-48938-00 Rivet (Eu0)Ymus |
90267-48938-00 |
from US $3.72 |
||
