Front wheel Diagram Honda ATC ATC125
- Model code
- ATC125M A
- Engine Capacity
- 125
- Year
- 1985
- Sales region
- USA
- Frame
- JH3TE010*FC100001 -
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Model
- ATC125
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
42712-968-000
Rim (outer)
|
42712-968-000 |
— | ||
|
2
|
2
42713-968-000
Rim (inner)
|
42713-968-000 |
— | ||
|
3
|
3
42750-VM6-681
Tire (22x11-8 pa-3)
|
42750-VM6-681 |
— | ||
|
3
|
3
42751-961-811
Tire (22x11-8)
(Optional). |
42751-961-811 |
— | ||
|
4
|
4
42753-SB8-661 ValveRIM (SCHRADER) |
42753-SB8-661 |
US $27.50 |
||
|
5
|
5
44301-943-000
Axle, fr. wheel
|
44301-943-000 |
— | ||
|
6
|
6
44302-968-680
Collar, fr. axle
|
44302-968-680 |
— | ||
|
7
|
7
44312-968-680
Colr, fr. axle side
|
44312-968-680 |
— | ||
|
8
|
8
44610-968-000
Hub, fr. wheel
|
44610-968-000 |
— | ||
|
9
|
9
44621-968-000
Collar, fr
|
44621-968-000 |
— | ||
|
10
|
10
44714-968-000
Patch, support plate
|
44714-968-000 |
— | ||
|
11
|
11
90101-942-000
Bolt, wheel
|
90101-942-000 |
— | ||
|
12
|
12
90103-943-300 Bolt, hub (8x25) |
90103-943-300 |
from US $6.79 |
||
|
13
|
13
90305-169-000 Nut, axle (12mm) |
90305-169-000 |
from US $5.33 |
||
|
14
|
14
90309-428-731 Nut, flange (self-lock) (m8x1.25) |
90309-428-731 |
from US $4.29 |
||
|
15
|
15
91251-958-004 Dust seal (23x42x7) |
91251-958-004 |
from US $10.73 |
||
|
16
|
16
91307-PH7-660 O-ring (13.5X1.4)13.5X1.4 |
91307-PH7-660 |
from US $4 |
||
|
17
|
17
91351-958-670 O-ring (160x4.2) |
91351-958-670 |
from US $13.72 |
||
|
20
|
20
94201-30250 PinSPLIT, 3.0X25 |
94201-30250 |
from US $0.44 |
||
| replacement | |||||
|
20
|
20
9420130450 Pin, cotter (3.0x45) |
9420130450 |
from US $0.44 |
||
|
20
|
20
9420130450 Pin, cotter (3.0x45) |
9420130450 |
from US $0.44 |
||
|
21
|
21
96150-6302010 Bearing (6302uu) |
96150-6302010 |
from US $9.18 |
||
