Front wheel Diagram Honda ATC ATC250
- Model code
- ATC250SX A
- Engine Capacity
- 250
- Year
- 1986
- Sales region
- USA
- Frame
- JH3TE042*GM100011 - JH3TE042*GM111920
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Model
- ATC250
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
42710-HA6-680
Rim comp.,wheel
|
42710-HA6-680 |
— | ||
|
2
|
2
42750-HA6-681AT
Tire (22x11.0-8)
|
42750-HA6-681AT |
— | ||
|
3
|
3
42753-VM0-003 Valve, rim |
42753-VM0-003 |
from US $10.06 |
||
|
4
|
4
44301-HA6-680
Axle,fr.wheel
|
44301-HA6-680 |
— | ||
|
5
|
5
44312-HA0-000
Collar b,distance
|
44312-HA0-000 |
— | ||
|
6
|
6
44601-HA6-680
Hub, fr. wheel
|
44601-HA6-680 |
— | ||
|
7
|
7
44620-HA6-680
Collar, fr
|
44620-HA6-680 |
— | ||
|
8
|
8
44624-HA0-000
Ring,damper
|
44624-HA0-000 |
— | ||
|
9
|
9
44625-HA0-680
Drum sub assy fr.
|
44625-HA0-680 |
— | ||
|
10
|
10
90103-HA2-003 Bolt, wheel (10x36) |
90103-HA2-003 |
from US $5.92 |
||
|
12
|
12
90314-VM0-771 Nut, wheel |
90314-VM0-771 |
from US $5.03 |
||
|
13
|
13
91251-958-004 Dust seal (23x42x7) |
91251-958-004 |
from US $10.73 |
||
|
16
|
16
91052-KR3-005 B/brg rad n/com |
91052-KR3-005 |
US $11.69 |
||
| replacement | |||||
|
16
|
16
91051-KEH-662 New Genuine Part |
91051-KEH-662 |
from US $13.91 |
||
