Exhaust cover Diagram Suzuki DF200 (Z)TL/X/XX
- Year
- 2014
- Model
- DF200
- Year
- 2014
- Engine
- 20002F-410001~ (20002Z-410001~)
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Power
- 200
- Sales region
- General Export No.1/Costa Rica (P01/P40)
- Colour
- Shadow Black Metallic (; 0EP)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
14141-93J01-000 COVER,EXHAUST STBD |
14141-93J01-000 |
US $72.13 |
||
|
2
|
2
14140-98J01-000 COVER,EXHAUST PORT |
14140-98J01-000 |
US $96.78 |
||
|
3
|
3
14151-93J00-000 GASKET,EXHAUST COVER(STBD)Gasket, exhaust cover stbd |
14151-93J00-000 |
from US $12.16 |
||
|
4
|
4
14152-93J00-000
GASKET,EXHAUST COVER(PORT)
|
14152-93J00-000 |
— | ||
| replacement | |||||
|
4
|
4
14152-93J01-000 EXHAUST TUBE SEAL |
14152-93J01-000 |
from US $15.44 |
||
|
5
|
5
11261-93J00-000 COVER,PROTECTION ANODE |
11261-93J00-000 |
from US $14.40 |
||
|
6
|
6
55321-87J00-000
Anode,protection
|
55321-87J00-000 |
— | ||
| replacement | |||||
|
6
|
6
55321-87J01-000 ANODE,PROTECTION |
55321-87J01-000 |
from US $7.58 |
||
|
7
|
7
09103-06281-000 BOLT(6X14)Bolt, protection anode |
09103-06281-000 |
from US $1.44 |
||
|
8
|
8
09280-22019-000 O RING(D:1.9,ID:21.8) |
09280-22019-000 |
from US $1.49 |
||
|
9
|
9
01550-08207-000 Bolt |
01550-08207-000 |
from US $1.12 |
||
|
10
|
10
01550-06257-000 Bolt |
01550-06257-000 |
from US $1.12 |
||
