	Description	OEM Part #	Price
1	1 689-11400-03-00 Crankshaft Assembly	689-11400-03-00	—
2	2 933-06306-04-00 Bearing	933-06306-04-00	—
3	3 93306-30564-00 Bearing	93306-30564-00	from US $53.51
	replacement
3	3 933-06305-71-00 Bearing	933-06305-71-00	from US $52.86
4	4 689-11636-00-00 Piston 2 O/s 0.50 Piston (2nd o.s.) O/S 0.50	689-11636-00-00	from US $83.03
4	4 689-11610-21-00 Piston Ring Set Os (2Nd O/s) OS 2ND O/S	689-11610-21-00	—
4	4 689-11631-00-95 Piston Std	689-11631-00-95	from US $141.44
	replacement
4	4 6K8-11631-00-95 Piston (Std) (Std)	6K8-11631-00-95	from US $79.32
7	7 689-11633-00-00 Pin, Piston	689-11633-00-00	from US $8.42
8	8 688-11634-00-00 Clip, Piston Pin	688-11634-00-00	from US $2.36
9	9 90201-20M27-00 Washer, Plate	90201-20M27-00	from US $5.40
10	10 93210-16275-00 O-Ring	93210-16275-00	from US $1.63
11	11 90201-50306-00 Washer, Plate	90201-50306-00	from US $4.86
12	12 932-1057M-09-00 O-Ring	932-1057M-09-00	from US $3.04
13	13 931-0125M-30-00 Oil Seal	931-0125M-30-00	US $9.35
	replacement
13	13 931-0225M-28-00 Oil Seal(6H4)	931-0225M-28-00	from US $9.44
14	14 931-0116M-36-00 Oil Seal	931-0116M-36-00	from US $5.06
15	15 689-15396-01-5B Housing, Oil Seal	689-15396-01-5B	US $35.99
	replacement
15	15 689-15396-01-CA Housing, Oil Seal	689-15396-01-CA	from US $31.79
16	16 97395-06022-00 Boulon	97395-06022-00	from US $2.27
	replacement
16	16 97095-06022-00 Bolt	97095-06022-00	from US $2.50
17	17 929-90066-00-00 Washer, Plain (646)	929-90066-00-00	from US $1.39

Crankcase piston Diagram Yamaha 30 ES/L U.S.A. 10694279-690733
