Intake Diagram Yamaha F70 L
- Year
- 2010
- Model
- F70
- Year
- 2010
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Power
- 70
- Sales region
- U.S.A.
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
6C5-13713-00-00
Valve, Idle Speed Control
|
6C5-13713-00-00 |
— | ||
| replacement | |||||
|
1
|
1
6C5-13713-02-00 Valve, Idle Speed Control |
6C5-13713-02-00 |
from US $167.97 |
||
|
2
|
2
979-80052-14-00 Screw, With Washer |
979-80052-14-00 |
from US $1.35 |
||
|
3
|
3
6CJ-11372-00-00 Nipple, Hose |
6CJ-11372-00-00 |
from US $13.03 |
||
|
4
|
4
932-10330-03-00 O-Ring |
932-10330-03-00 |
from US $3.54 |
||
|
5
|
5
6CJ-13543-00-00 Hose, Air |
6CJ-13543-00-00 |
from US $27.34 |
||
|
6
|
6
904-6511M-10-00
Clamp
|
904-6511M-10-00 |
— | ||
| replacements | |||||
|
6
|
6
80L-26397-00-00 Band |
80L-26397-00-00 |
from US $1.40 |
||
|
6
|
6
904-65100-98-00 Clamp |
904-65100-98-00 |
from US $1.39 |
||
|
7
|
7
6CJ-12576-00-00 Hose 1 |
6CJ-12576-00-00 |
from US $24.79 |
||
|
8
|
8
90464-15008-00 Clamp |
90464-15008-00 |
from US $2.98 |
||
|
9
|
9
90464-12006-00 Clamp |
90464-12006-00 |
from US $2.41 |
||
|
10
|
10
90464-15007-00 Clamp |
90464-15007-00 |
from US $3.54 |
||
|
11
|
11
90464-15007-00 Clamp |
90464-15007-00 |
from US $3.54 |
||
|
12
|
12
6CJ-1531A-00-00 Hose, Breather 1 |
6CJ-1531A-00-00 |
from US $61.76 |
||
