Ca175 headlight case Diagram Honda CA175 Touring
- Year
- 1969
- Model code
- CA175K3 A
- Sales region
- USA
- Frame
- CD1752005045 -
- Engine Capacity
- 175
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
34902-202-000 Bulb, dash (6v 3w) |
34902-202-000 |
from US $2.66 |
||
|
2
|
2
34908-001-000 Bulb (6v1.5w) |
34908-001-000 |
from US $8.82 |
||
|
3
|
3
37200-303-682
Speedometer assy
|
37200-303-682 |
— | ||
|
4
|
4
44830-303-010
Cable,speedometer
|
44830-303-010 |
— | ||
|
5
|
5
61301-302-650-B
Case,head light
|
61301-302-650-B |
— | ||
|
5
|
5
61301-302-650XJ
Case head,light
|
61301-302-650XJ |
— | ||
|
5
|
5
61301-302-650XK
Case,head light
|
61301-302-650XK |
— | ||
|
6
|
6
61302-230-010
Colr, headlight case
|
61302-230-010 |
— | ||
|
7
|
7
61302-230-620 Collar,light case |
61302-230-620 |
US $6.17 |
||
|
8
|
8
61303-230-000
Washer
|
61303-230-000 |
— | ||
|
9
|
9
61304-292-000 Collar |
61304-292-000 |
from US $3.40 |
||
|
10
|
10
61305-303-000
Plate,back
|
61305-303-000 |
— | ||
|
11
|
11
92101-08025-0A Bolt, hex., 8x25 |
92101-08025-0A |
from US $0.59 |
||
|
13
|
13
9350006010 Screw, pan, 6x10 |
9350006010 |
US $1.46 |
||
| replacement | |||||
|
13
|
13
93500-060100A Screw, pan, 6x10 |
93500-060100A |
from US $0.44 |
||
|
15
|
15
94101-06800 WasherPLAIN, 6MM |
94101-06800 |
from US $0.37 |
||
|
16
|
16
94111-08000 WasherSPRING, 8MM |
94111-08000 |
from US $0.37 |
||
