フロントブレーキ Diagram Kawasaki EX250 Ninja 250
- Year
- 2015
- Colour
- Lime Green (777)
- Model code
- EX250MFF
- Sales region
- Japan
- Engine Capacity
- 250
- Frame
- EX250L-011001-017000
- Engine
- EX250LE000001-
- Model
- EX250 Ninja 250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
21007
|
21007
21007-0578 ROTOR,FRFR |
21007-0578 |
from US $21.23 |
||
|
41080
|
41080
41080-0578-11H DISC,FR,BLACKFR，ブラツク |
41080-0578-11H |
from US $326.70 |
||
|
43044
|
43044
43044-1112 HOLDER-COMP-CALIPERキヤリパ |
43044-1112 |
from US $75.55 |
||
|
43045
|
43045
43045-0004 SHAFT-CALIPERキヤリパ |
43045-0004 |
from US $14.10 |
||
|
43045A
|
43045A
43045-1010 SHAFT-CALIPERキヤリパ |
43045-1010 |
from US $14.10 |
||
|
43048
|
43048
43048-1068 PISTON-CALIPERキヤリパ |
43048-1068 |
from US $56.40 |
||
|
43049
|
43049
43049-1060 PACKING,PISTON SEAL |
43049-1060 |
from US $13.46 |
||
|
43049A
|
43049A
43049-1061 PACKING,PISTON SEAL |
43049-1061 |
from US $7.44 |
||
|
43056
|
43056
43056-1055 Breather-brake |
43056-1055 |
from US $8.41 |
||
| replacement | |||||
|
43056
|
43056
43056-1056 BREATHER,BRAKE |
43056-1056 |
from US $10.14 |
||
|
43057
|
43057
43057-1001 CAP-BREATHERブリ-ザ |
43057-1001 |
from US $3.48 |
||
|
43080
|
43080
43080-0150-25S CALIPER-SUB-ASSY,FR,B |
43080-0150-25S |
from US $291.85 |
||
|
43082
|
43082
43082-0081 PAD-ASSY-BRAKEブレ-キ |
43082-0081 |
from US $49.52 |
||
|
49006
|
49006
49006-1088 BOOT,CALIPER |
49006-1088 |
from US $8.55 |
||
|
49006A
|
49006A
49006-1242 BOOT |
49006-1242 |
from US $3.64 |
||
|
92001
|
92001
92001-1041 BOLT,HEX HEAD,8X36 |
92001-1041 |
from US $6.34 |
||
|
92022
|
92022
92022-1373 WASHER |
92022-1373 |
from US $2.53 |
||
|
92043
|
92043
92043-1416 PIN,HUNGER |
92043-1416 |
from US $12.04 |
||
|
92144
|
92144
92144-1847 SPRING, PAD |
92144-1847 |
from US $19.64 |
||
|
92154
|
92154
92154-1865 BOLT,SOCKET,8X30 |
92154-1865 |
from US $2.85 |
||
|
92210
|
92210
92210-0615 NUT |
92210-0615 |
from US $3.17 |
||
