Clutch Diagram KTM 50 50 SX Mini
- Year
- 2014
- Sales region
- US/EU
- Engine Capacity
- 50
- Model
- 50 SX Mini
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
45232100144 Axial Clutch AssemblyAs Required |
45232100144 |
US $808.84 |
||
|
2
|
2
45232101000 Clutch BasketAs Required |
45232101000 |
US $64.46 |
||
|
3
|
3
45232139044 Ball Cage AssemblyAs Required |
45232139044 |
US $146.71 |
||
|
4
|
4
45232110033 Clutch Disc KitAs Required |
45232110033 |
US $158.92 |
||
|
5
|
5
0035080206S Ah-collar screw m8x20 isa45As Required |
0035080206S |
US $6.73 |
||
|
6
|
6
0401110000 Ball D=11MmAs Required |
0401110000 |
US $0.73 |
||
|
7
|
7
45232103000 Pressure PlateAs Required |
45232103000 |
US $32.50 |
||
|
8
|
8
0991060166S Fl.head Scr.din7991-M6X16 10.9As Required |
0991060166S |
US $2.04 |
||
| replacement | |||||
|
8
|
8
010642060166S FL.HEAD SCR.DIN7991-M6X16 10.9As Required |
010642060166S |
US $2.04 |
||
|
9
|
9
45232105000 Clutch Spring 15,9MmAs Required |
45232105000 |
US $8.21 |
||
|
10
|
10
0340084234 Washer Din 6340 8,4X23X4As Required |
0340084234 |
US $0.66 |
||
|
11
|
11
45232107244 Fit Bolt With Drive PlateAs Required |
45232107244 |
US $149.96 |
||
|
12
|
12
75034050000 Stop disk 14x30x1,5 steelAs Required |
75034050000 |
US $3.72 |
||
|
13
|
13
0402182412 Needle bearing 18x24x12aAs Required |
0402182412 |
US $17.75 |
||
|
14
|
14
45232013000 Inner ring with collarAs Required |
45232013000 |
US $41.87 |
||
| replacement | |||||
|
14
|
14
45232013100 Inner ring with collarAs Required |
45232013100 |
US $41.87 |
||
|
15
|
15
09910601661S Fl.head Scr.din7991-M6X16 10.9As Required |
09910601661S |
US $2.02 |
||
| replacement | |||||
|
15
|
15
0106420601602S Fl.head Scr.din7991-M6X16 10.9As Required |
0106420601602S |
US $2.02 |
||
