Break Caliper Front Diagram KTM 500 500 XC-W
- Year
- 2015
- Sales region
- US/EU
- Engine Capacity
- 500
- Model
- 500 XC-W
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
54813080101 Brake Cal. Re. - Without Pads2000 |
54813080101 |
US $249.75 |
||
|
2
|
2
50313081200 Repair kit sealing rings 26mm2000 |
50313081200 |
US $17.95 |
||
|
3
|
3
54813082000 Bolt Set For Brake Caliper 0303 |
54813082000 |
US $28.76 |
||
|
4
|
4
54813090300 Brake pad set rear toyo03 |
54813090300 |
US $97.34 |
||
|
5
|
5
77713083000 Brake Piston 26Mm 20132013 |
77713083000 |
US $49.61 |
||
|
6
|
6
54813018000 Retaining spring set 20032003 |
54813018000 |
US $36.19 |
||
|
7
|
7
54813075000 Brake caliper support rear2003 |
54813075000 |
US $153.48 |
||
|
8
|
8
54613218000 Cup Set Short2003 |
54613218000 |
US $25.72 |
||
| replacement | |||||
|
8
|
8
54613218100 CUP SET SHORT2003 |
54613218100 |
US $25.72 |
||
|
10
|
10
54813070100 Brake Hose Rear 655Mm 1515 |
54813070100 |
US $60.23 |
||
|
11
|
11
62513020000 Bleeder Screw Cpl. 0505 |
62513020000 |
US $30.16 |
||
|
12
|
12
0603100141 Copper Gasket Din7603-10X14X105 |
0603100141 |
US $2.24 |
||
