Head Light Support, Attachment Diagram KTM 640 640 Adventure R
- Year
- 1998
- Sales region
- US/EU
- Engine Capacity
- 640
- Model
- 640 Adventure R
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
58214010000 Support F.cockpit Adventure660 LC4 |
58214010000 |
US $107.54 |
||
| replacement | |||||
|
1
|
1
58214010100
Head light carrier triom adv.
660 LC4 |
58214010100 |
— | ||
|
2
|
2
58211045000
Support f. head light adv. '97
660 LC4 |
58211045000 |
— | ||
|
4
|
4
49001426000
Rubber grommet 20x10-m6x12 (2)
660 LC4 |
49001426000 |
— | ||
|
5
|
5
54335031000 Rubber grommet 20x15-m6x10 (2)660 LC4 |
54335031000 |
US $10 |
||
|
6
|
6
0125060003 Washer Din0125-A 6,4660 LC4 |
0125060003 |
US $0.37 |
||
|
7
|
7
0934060003 Hexagon Nut Din0934-M 6660 LC4 |
0934060003 |
US $0.43 |
||
|
8
|
8
0021060003 Washer Din9021-A 6,4660 LC4 |
0021060003 |
US $3.26 |
||
|
9
|
9
0015060253
Hh Collar Screw M6X25 Tx30
660 LC4 |
0015060253 |
— | ||
| replacement | |||||
|
9
|
9
0025060256 Hh collar screw m6x25 tx30660 LC4 |
0025060256 |
US $2.45 |
||
|
10
|
10
56509064000 Self Locking Nut M6 10.9660 LC4 |
56509064000 |
US $1.14 |
||
| replacement | |||||
|
10
|
10
56509064100 Self Locking Nut M6 10.9660 LC4 |
56509064100 |
US $1.04 |
||
|
11
|
11
0015080503 Hh collar screw m 8x50 ws=10660 LC4 |
0015080503 |
US $1.65 |
||
|
12
|
12
54310086000
Self Locking Nut M8 10.9
660 LC4 |
54310086000 |
— | ||
| replacement | |||||
|
12
|
12
54310086200 Self Locking Nut M8 10.9660 LC4 |
54310086200 |
US $1.56 |
||
|
14
|
14
43205062100 Rubber grommet 20x15-m6x10 (1)660 LC4 |
43205062100 |
US $24.07 |
||
|
15
|
15
0014060103
Hh Collar Screw M6X10 Tx30
660 LC4 |
0014060103 |
— | ||
| replacement | |||||
|
15
|
15
0024060106 Hh collar screw m6x10 tx30660 LC4 |
0024060106 |
US $4.35 |
||
|
20
|
20
0797060003 Tooth Lock Wash. Din6797-A 6,4660 LC4 |
0797060003 |
US $0.29 |
||
