Clutch Diagram KTM 690 690 Duke
- Year
- 2013
- Sales region
- US/EU
- Engine Capacity
- 690
- Model
- 690 Duke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
0025050256 Hh collar screw m5x25 isa30AS REQUIRED |
0025050256 |
US $0.66 |
||
|
2
|
2
75032006000 Spring ring 0707 |
75032006000 |
US $5.20 |
||
|
3
|
3
58532080001 Clutch spring 3,0x33,507 |
58532080001 |
US $11.44 |
||
|
4
|
4
75032003000 Pressure cap07 |
75032003000 |
US $141.92 |
||
|
5
|
5
60036073050 Hexagon nut m20x1,5 7mm07 |
60036073050 |
US $8.67 |
||
| replacement | |||||
|
5
|
5
60036073150 Hexagon nut m20x1,5 h=6mm 0507 |
60036073150 |
US $5.95 |
||
|
6
|
6
75032018000
Lock washer 07
07 |
75032018000 |
— | ||
| replacement | |||||
|
6
|
6
47032020000 Stop disc 20x32x207 |
47032020000 |
US $5.20 |
||
|
7
|
7
75032002002 Inner clutch hub movable07 |
75032002002 |
US $553.13 |
||
|
8
|
8
75032033000 Clutch release spring07 |
75032033000 |
US $6.77 |
||
|
9
|
9
75032002001 Inner clutch hub fixed07 |
75032002001 |
US $518.72 |
||
|
10
|
10
75032009000 Stepped washer 0707 |
75032009000 |
US $7.99 |
||
|
11
|
11
75032007000 Half-washer 0707 |
75032007000 |
US $11.29 |
||
|
12
|
12
75032001044 Outer clutch hub cpl.07 |
75032001044 |
US $741.49 |
||
| replacement | |||||
|
12
|
12
75032001144 Clutch Cage Cpl. 79T07 |
75032001144 |
US $545.33 |
||
|
14
|
14
75032050001 Oil pump drive wheel 0707 |
75032050001 |
US $3.11 |
||
|
15
|
15
56532095000 Needle bearing k26x30x22zw.kse07 |
56532095000 |
US $21.51 |
||
|
16
|
16
75032017000 Washer 26x40x2 0707 |
75032017000 |
US $5.39 |
||
|
17
|
17
0625060016 Groov.ball bear. 6001.2rsr c307 |
0625060016 |
US $23.89 |
||
|
18
|
18
75032055100 Pressure bolt 0808 |
75032055100 |
US $12.53 |
||
|
19
|
19
75032054200 Push rod 0808 |
75032054200 |
US $18.90 |
||
|
20
|
20
59032065000
Gasket for slave cylinder
08 |
59032065000 |
— | ||
| replacement | |||||
|
20
|
20
59032065100 Gasket For Slave Cylinder08 |
59032065100 |
US $7.21 |
||
|
21
|
21
0770300015 O-ring 30,00x1,50 nbr 7008 |
0770300015 |
US $3.26 |
||
|
23
|
23
54732064000 Bleeder Screw With Cap08 |
54732064000 |
US $22.05 |
||
|
24
|
24
75032061044 Output Cyl. With Bleeder Screw08 |
75032061044 |
US $230.98 |
||
|
26
|
26
0025060356 Hh collar screw m6x35 tx30TX30 |
0025060356 |
US $6.15 |
||
|
27
|
27
0025060206 Hh collar screw m6x20 tx30TX30 |
0025060206 |
US $1.97 |
||
|
28
|
28
75032112000 Steel disk 1,5 mm lc4 ┤0707 |
75032112000 |
US $16.47 |
||
|
29
|
29
58332011300 Lining disk 2,7mm fcc 0202 |
58332011300 |
US $26.47 |
||
|
30
|
30
58632016000 Rondella antivibrazione set02 |
58632016000 |
US $64.75 |
||
|
31
|
31
75032111100 Lining disc cut out02 |
75032111100 |
US $42.01 |
||
|
32
|
32
75032112100 Steel disk 1,5mm nitrided02 |
75032112100 |
US $29.09 |
||
|
33
|
33
75032032000 Holding screw gmb-m5x3502 |
75032032000 |
US $7 |
||
|
99
|
99
75032011110 Clutch kit 690 lc4 08-1002 |
75032011110 |
US $438.18 |
||
