Water Pump Diagram KTM 690 690 Duke
- Year
- 2013
- Sales region
- US/EU
- Engine Capacity
- 690
- Model
- 690 Duke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
75035017000 Thermostat 0707 |
75035017000 |
US $36.19 |
||
|
2
|
2
60040027050 Supporting sleeve 0303 |
60040027050 |
US $6.41 |
||
|
3
|
3
0025060206 Hh collar screw m6x20 tx30TX30 |
0025060206 |
US $1.97 |
||
|
4
|
4
75035016000 Thermostatcover 0707 |
75035016000 |
US $5.53 |
||
|
5
|
5
0025060306 Hh collar screw m6x30 tx30TX30 |
0025060306 |
US $3.96 |
||
|
6
|
6
7503505210033 Waterpump cover 1010 |
7503505210033 |
US $98.29 |
||
|
7
|
7
75035053000 Water pump cover gasket 0707 |
75035053000 |
US $8.89 |
||
|
8
|
8
0024060156 Hh collar screw m6x15 tx30TX30 |
0024060156 |
US $3.96 |
||
|
9
|
9
75035055000 Water pump rotor 0707 |
75035055000 |
US $5.20 |
||
|
10
|
10
60035055150 Form washer 16x1 niro 0303 |
60035055150 |
US $1.31 |
||
|
11
|
11
0760123071 Shaft seal ring. 12x30x7 viton03 |
0760123071 |
US $10 |
||
|
14
|
14
0760123073 Shaft seal ring 12x30x7 ptfe03 |
0760123073 |
US $16.13 |
||
|
15
|
15
0474050100 Grooved pin din1474 5x1003 |
0474050100 |
US $2.60 |
||
|
99
|
99
75035055010 Water Pump Rep. Kit 690AS REQUIRED |
75035055010 |
US $36.91 |
