Instruments / Lock System Diagram KTM HUSABERG TE 250
- Year
- 2013
- Sales region
- US/EU
- Engine Capacity
- 250
- Model
- TE 250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
54814069100 Speedometer mph f. 21" 20052005 |
54814069100 |
US $327.52 |
||
|
2
|
2
54814069010 Battery cover f. speedom. 20052005 |
54814069010 |
US $12.41 |
||
|
3
|
3
58314068000 Battery f. speedom. m.a.e. 0202 |
58314068000 |
US $9.64 |
||
|
4
|
4
54814069020 Speedometer top part 0505 |
54814069020 |
US $30.94 |
||
|
10
|
10
54814068100 Cable for digital speedom. 0606 |
54814068100 |
US $90.73 |
||
|
11
|
11
60111094000 Clamp 5/7 mm 0606 |
60111094000 |
US $3.54 |
||
|
12
|
12
54814069050 Magnet For Digital Speedom. 0303 |
54814069050 |
US $23.21 |
||
|
13
|
13
0471009104 Circlip Din0471- 9X1 Inox03 |
0471009104 |
US $2.35 |
||
|
20
|
20
54814060100 Speedometer bracket xc-w 0808 |
54814060100 |
US $1.14 |
||
|
21
|
21
0081645121 Ejot Delta Pt Screw 45X12-Z08 |
0081645121 |
US $1.17 |
||
|
22
|
22
58214069051 Rubber Grommet 16X10,8X3 0202 |
58214069051 |
US $4.52 |
||
|
23
|
23
31008060000 Rubber Sleeve D=8Mm Open02 |
31008060000 |
US $1.09 |
||
|
24
|
24
0025060206 Hh collar screw m6x20 tx30TX30 |
0025060206 |
US $1.97 |
||
|
25
|
25
59030060050 Bushing F. Sprocket Cover RacTX30 |
59030060050 |
US $2.09 |
||
|
42
|
42
54813026000 Cable support 10/6mm 0606 |
54813026000 |
US $2.35 |
