Flasher light Diagram Yamaha EA06 Passol
- Year
- 2003
- Colour
- Vivid Orange Solid 1 (VOS1; 0905)
- Model code
- 5UY2
- Sales region
- Japan (010)
- Engine Capacity
- 0
- Color Variant
- E
- Model
- EA06
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
2
|
2
5UY-83312-10-00 Lens, Flasher．レンズ，フラツシヤ; |
5UY-83312-10-00 |
US $5.41 |
||
|
3
|
3
5UY-83311-01-00 Bulb, Flasher (24V-10W)．バルブ，フラツシヤ ; ２４Ｖ−１０Ｗ |
5UY-83311-01-00 |
US $5.68 |
||
|
4
|
4
5UY-83333-00-00 Screw, Lens Fitting．スクリユ，レンズフイツテイング; |
5UY-83333-00-00 |
US $3.54 |
||
|
5
|
5
5UY-8333F-00-00 Washer．ワツシヤ; |
5UY-8333F-00-00 |
US $3.54 |
||
|
6
|
6
5UY-83320-01-00 Front Flasher Light Assy 2 |
5UY-83320-01-00 |
US $26.49 |
||
|
7
|
7
5UY-83312-00-00 Lens, Flasher．レンズ，フラツシヤ; |
5UY-83312-00-00 |
US $5.41 |
||
|
8
|
8
5UY-83311-01-00 Bulb, Flasher (24V-10W)．バルブ，フラツシヤ ; ２４Ｖ−１０Ｗ |
5UY-83311-01-00 |
US $5.68 |
||
|
9
|
9
5UY-83333-00-00 Screw, Lens Fitting．スクリユ，レンズフイツテイング; |
5UY-83333-00-00 |
US $3.54 |
||
|
10
|
10
5UY-8333F-00-00 Washer．ワツシヤ; |
5UY-8333F-00-00 |
US $3.54 |
||
|
11
|
11
90201-05725-00 Washer, Plateワツシヤ，プレート; |
90201-05725-00 |
from US $1.70 |
||
|
12
|
12
977-07500-20-00
Screw, Tapping
|
977-07500-20-00 |
— | ||
| replacement | |||||
|
12
|
12
90167-05078-00 Screw, Tapping |
90167-05078-00 |
from US $1.56 |
||
|
13
|
13
5UY-83330-01-00 Rear Flasher Light Assy 1 |
5UY-83330-01-00 |
US $26.07 |
||
|
14
|
14
5UY-83312-00-00 Lens, Flasher．レンズ，フラツシヤ; |
5UY-83312-00-00 |
US $5.41 |
||
|
15
|
15
5UY-83311-01-00 Bulb, Flasher (24V-10W)．バルブ，フラツシヤ ; ２４Ｖ−１０Ｗ |
5UY-83311-01-00 |
US $5.68 |
||
|
16
|
16
5UY-83333-00-00 Screw, Lens Fitting．スクリユ，レンズフイツテイング; |
5UY-83333-00-00 |
US $3.54 |
||
|
17
|
17
5UY-8333F-00-00 Washer．ワツシヤ; |
5UY-8333F-00-00 |
US $3.54 |
||
|
18
|
18
5UY-83340-01-00 Rear Flasher Light Assy 2 |
5UY-83340-01-00 |
US $30.65 |
||
|
19
|
19
5UY-83312-10-00 Lens, Flasher．レンズ，フラツシヤ; |
5UY-83312-10-00 |
US $5.41 |
||
|
20
|
20
5UY-83311-01-00 Bulb, Flasher (24V-10W)．バルブ，フラツシヤ ; ２４Ｖ−１０Ｗ |
5UY-83311-01-00 |
US $5.68 |
||
|
21
|
21
5UY-83333-00-00 Screw, Lens Fitting．スクリユ，レンズフイツテイング; |
5UY-83333-00-00 |
US $3.54 |
||
|
22
|
22
5UY-8333F-00-00 Washer．ワツシヤ; |
5UY-8333F-00-00 |
US $3.54 |
||
|
23
|
23
90167-05080-00 Screw, Tapping |
90167-05080-00 |
from US $1.66 |
||
|
24
|
24
5UY-83318-00-00 Stay, Flasher 1ステー，フラツシヤ １; |
5UY-83318-00-00 |
US $8.98 |
||
|
25
|
25
90159-05117-00 Screw, With Washer(J38) |
90159-05117-00 |
from US $1.56 |
||
| replacement | |||||
|
25
|
25
97607-05212-00 Screw, With Washer |
97607-05212-00 |
from US $1.56 |
||
