Intake Diagram Yamaha SR125
- Year
- 1988
- Colour
- Yamaha Black (YB; 0033)
- Model code
- 2JW
- Sales region
- Spain (999)
- Engine Capacity
- 125
- Model
- SR125
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
36X-13586-00-00 Joint, Carburetor 1 |
36X-13586-00-00 |
US $35.78 |
||
| replacement | |||||
|
01
|
01
36X-13586-01-00 Joint, Carburetor 1 |
36X-13586-01-00 |
US $30.99 |
||
|
02
|
02
932-10355-37-00
O-Ring
|
932-10355-37-00 |
— | ||
| replacement | |||||
|
02
|
02
93210-35803-00 O-Ring |
93210-35803-00 |
from US $1.85 |
||
|
03
|
03
913-16060-20-00
Bolt
|
913-16060-20-00 |
— | ||
| replacement | |||||
|
03
|
03
91317-06020-00 Bolt |
91317-06020-00 |
from US $1.18 |
||
|
04
|
04
90460-43817-00
Clamp, Hose
|
90460-43817-00 |
— | ||
|
05
|
05
21L-E4401-00-00
Air Cleaner Case Assy
|
21L-E4401-00-00 |
— | ||
|
06
|
06
2JW-E4453-00-00
Joint, Air Cleaner 1
|
2JW-E4453-00-00 |
— | ||
|
07
|
07
21L-E4437-00-00
Duct
|
21L-E4437-00-00 |
— | ||
|
08
|
08
21L-E4458-00-00
Guide
|
21L-E4458-00-00 |
— | ||
| replacement | |||||
|
08
|
08
21L-E4450-00-00
Cartucho Filtrante
|
21L-E4450-00-00 |
— | ||
|
09
|
09
21L-E4451-00-00
Element, Air Cleaner
|
21L-E4451-00-00 |
— | ||
|
10
|
10
21L-E4468-00-00
Plate,element Fitting
|
21L-E4468-00-00 |
— | ||
|
11
|
11
21L-E4402-00-00
Cap Assy, Air Cleaner
|
21L-E4402-00-00 |
— | ||
|
12
|
12
21L-E4452-00-00
Seal
|
21L-E4452-00-00 |
— | ||
| replacement | |||||
|
12
|
12
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
13
|
13
90446-11023-00 Hose |
90446-11023-00 |
from US $3.97 |
||
| replacement | |||||
|
13
|
13
91A21-07020-00 Hose |
91A21-07020-00 |
from US $4.30 |
||
|
14
|
14
90480-12053-00 Grommet |
90480-12053-00 |
from US $1.94 |
||
|
15
|
15
98501-05010-00 Screw, Pan Head |
98501-05010-00 |
US $1.21 |
||
| replacement | |||||
|
15
|
15
97885-05010-00 Screw, Pan Head |
97885-05010-00 |
from US $1.18 |
||
|
16
|
16
929-01056-00-00
Washer
|
929-01056-00-00 |
— | ||
| replacements | |||||
|
16
|
16
92990-05600-00 Washer, Plate |
92990-05600-00 |
from US $1.07 |
||
|
16
|
16
92907-05600-00 Washer, Plate |
92907-05600-00 |
from US $1.18 |
||
|
17
|
17
90480-16185-00 Grommet |
90480-16185-00 |
from US $3.12 |
||
|
18
|
18
21L-E4498-00-00
Stay 1
|
21L-E4498-00-00 |
— | ||
|
19
|
19
97701-40110-00 Screw, Tapping |
97701-40110-00 |
US $1.56 |
||
| replacement | |||||
|
19
|
19
97780-40110-00 Screw, Tapping |
97780-40110-00 |
from US $1.56 |
||
|
20
|
20
90460-56816-00
Clamp, Hose
|
90460-56816-00 |
— | ||
| replacement | |||||
|
20
|
20
90450-60X00-00
Hose Clamp
|
90450-60X00-00 |
— | ||
|
21
|
21
95801-06010-00 Bolt, Flange |
95801-06010-00 |
from US $1.07 |
||
| replacements | |||||
|
21
|
21
95817-06010-00 Bolt, Flange |
95817-06010-00 |
from US $1.18 |
||
|
21
|
21
95812-06010-00 Bolt, Flange |
95812-06010-00 |
from US $1.07 |
||
|
22
|
22
904-80011-41-00
Grommet
|
904-80011-41-00 |
— | ||
| replacement | |||||
|
22
|
22
90480-01401-00 Grommet (41Y) |
90480-01401-00 |
from US $3.05 |
||
|
23
|
23
16G-13569-00-00 Plug, Blind |
16G-13569-00-00 |
from US $2.36 |
||
|
24
|
24
90467-10039-00 Clip |
90467-10039-00 |
from US $1.39 |
||
