Instrument panel Diagram Yamaha EX440 Exciter
- Model code
- EX440
- Engine Capacity
- 440
- Year
- 1980
- Sales region
- USA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8G6-77711-00-00
Panel, Instrument
|
8G6-77711-00-00 |
— | ||
|
2
|
2
985-06060-16-00
Screw Pan Head
|
985-06060-16-00 |
— | ||
| replacement | |||||
|
2
|
2
98507-06016-00 Screw, Pan Head |
98507-06016-00 |
from US $1.52 |
||
|
3
|
3
902-01060-59-00
Washer, Plate
|
902-01060-59-00 |
— | ||
| replacements | |||||
|
3
|
3
90201-06057-00 Washer, Plate |
90201-06057-00 |
from US $1.28 |
||
|
3
|
3
90201-06020-00 Washer, Plate |
90201-06020-00 |
from US $1.56 |
||
|
4
|
4
904-64040-10-00
Clamp
|
904-64040-10-00 |
— | ||
|
5
|
5
95701-06300-00 Nut, Nylon |
95701-06300-00 |
from US $1.56 |
||
| replacement | |||||
|
5
|
5
95707-06300-00 Nut, Nylon |
95707-06300-00 |
from US $1.52 |
||
|
6
|
6
902-01060-59-00
Washer, Plate
|
902-01060-59-00 |
— | ||
| replacements | |||||
|
6
|
6
90201-06057-00 Washer, Plate |
90201-06057-00 |
from US $1.28 |
||
|
6
|
6
90201-06020-00 Washer, Plate |
90201-06020-00 |
from US $1.56 |
||
|
7
|
7
8J7-77715-00-00
Ormnt, Instr Pnl 1
|
8J7-77715-00-00 |
— | ||
|
8
|
8
8G6-77761-00-00
Label, Warning 1
|
8G6-77761-00-00 |
— | ||
|
9
|
9
878-77743-00-00 Indicator 3 |
878-77743-00-00 |
US $3.31 |
||
|
10
|
10
878-77744-00-00
Indicator 4
|
878-77744-00-00 |
— | ||
| replacement | |||||
|
10
|
10
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
11
|
11
878-77745-00-00
Indicator 5
|
878-77745-00-00 |
— | ||
| replacement | |||||
|
11
|
11
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
12
|
12
8E7-77742-00-00
Indicator 2
|
8E7-77742-00-00 |
— | ||
|
13
|
13
8G6-77765-00-00
Label, Warning 5
|
8G6-77765-00-00 |
— | ||
