Electrical (3) Diagram Yamaha VT480 Venture 480 GT
- Model code
- VT480GTS
- Engine Capacity
- 485
- Year
- 1992
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- Model
- Venture 480 GT
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
3Y6-85130-02-00 Reflector |
3Y6-85130-02-00 |
from US $12.80 |
||
|
2
|
2
957-01055-00-00
Nut, Flange
|
957-01055-00-00 |
— | ||
| replacement | |||||
|
2
|
2
95707-05500-00 Nut, Flange |
95707-05500-00 |
from US $1.07 |
||
|
3
|
3
81E-85110-00-00
Reflector Assembly
|
81E-85110-00-00 |
— | ||
|
4
|
4
87K-8511E-00-00 Base,reflector 2 |
87K-8511E-00-00 |
from US $17.19 |
||
|
5
|
5
87K-8511F-00-00 Base, Reflector 3 |
87K-8511F-00-00 |
from US $17.19 |
||
|
6
|
6
929-01056-00-00
Washer
|
929-01056-00-00 |
— | ||
| replacements | |||||
|
6
|
6
92990-05600-00 Washer, Plate |
92990-05600-00 |
from US $1.07 |
||
|
6
|
6
92907-05600-00 Washer, Plate |
92907-05600-00 |
from US $1.18 |
||
|
7
|
7
95701-05300-00 Nut, Flange |
95701-05300-00 |
US $1.42 |
||
| replacement | |||||
|
7
|
7
95707-05300-00 Nut, Flange |
95707-05300-00 |
from US $1.42 |
||
